Switch board
Block No. [0][2]
Mechanism control board
Block No. [0][3]
CN962 QGF0534F1-45X CONNECTOR FFC/FPC (1-45)
CN963 QGB2027L8-30X CONNECTOR B-B (1-30)
J331 QNN0519-001 PIN JACK
J801 QNZ0095-001 CONNECTOR
K401 NQR0007-002X FERRITE BEADS
K402 NQR0007-002X FERRITE BEADS
K411 NQR0201-004X FERRITE BEADS
K922 NQR0201-004X FERRITE BEADS
PP2 QZW0010-001 STYLE PIN
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S723 QSW1049-001Z TACT SW
TH721 NAD0028-103X N THERMISTOR 10k
Ω
TU21 QAU0312-002 TUNER PACK
W21 QAM0105-003 CAR CABLE
X31 QAX0616-001Z CRYSTAL 10.250MHz
X721 QAX0617-001Z CRYSTAL 12.500MHz
X722 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC601 PT6523LQ-L IC
IC602 RPM7338-V4 RM.RECEIVER
Q640 2SB624/4/-X TRANSISTOR
Q641 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D640 MA152WK-X SI DIODE
D641 UDZS5.1B-X Z DIODE
D642 MA111-X SI DIODE
D643 MA8062/M/-X Z DIODE
D645 NSPW310BS/BRS/ LED
D646 NSPW310BS/BRS/ LED
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R606 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R608 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R609 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R610 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R611 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R612 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R613 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R614 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R630 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R631 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R632 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R633 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R634 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R636 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R638 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R640 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R641 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R642 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R643 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R644 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R646 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R648 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R660 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R661 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R670 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R672 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
R673 NRSA02J-473X MG RESISTOR 47k
Ω
1/10W J
R674 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R691 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R692 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
CN601 NNZ0085-001 CAR CONNECTOR
EN601 QSW1115-002 ROTARY ENCODER
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH
Symbol No.
Part No. Part Name Description Local
IC201 BA5835FM-X IC
IC251 BD6671FM-X IC
IC301 MN2DS0003AA-H IC
IC302 BA00HC5WF-X IC
IC304 S-80827CNNB-G-W IC
IC398 SG32M90TFIR3 IC(MICRO C ROM)
IC398 SG32M90TFIR31B IC(PROGRAMED)
IC399 K4S281632F-UC75 IC(DIGITAL)
IC399 or EDS1216AATA-75 IC(DIGITAL)
IC401 AK4385ET-X IC
IC411 NJM4565V-X IC
IC481 BR93L66F-W-X IC
Q101 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Symbol No.
Part No. Part Name Description Local
