JVC KD-S50 User Manual

KD-S50
3-3
Item
Parts number Parts name Area
A
Parts list (General)
Q'ty
Description
Block No. M1MM
1 ---------------
CD MECHA
1
2 FSJC1029-021
TOP CHASSIS
1
3 FSMH3001-002
HEAT SINK
1
4 FSKM3011-002
BOTTOM COVER
1
5 FSMA3004-003
INSULATOR
1
6 QYSDST2604Z
SCREW
3
CHASSIS+MECHA BKT
7 FSKZ4005-001
SCREW
2
CHASSIS+SIDE PANEL
8 QYSDST2604Z
SCREW
3
CHASSIS+REAR BKT
9 QYSDST2606Z
SCREW
2
CHASSIS+MAIN PWB
10 FSKZ4005-001
SCREW
1
SIDE PANEL+IC BKT
11 FSJC2013-013
FRONT CHASSIS
1
12 FSKS3010-001
LOCK LEVER
1
13 FSKW4005-003
TORSION SPRING
1
LOCK LEVER
14 FSXP3026-002
RLS KNOB
1
15 FSKW3002-015
COMP.SPRING
1
16 FSPK3009-002
BLIND
1
17 FSJC1057-002
FRONT PANEL
1
18 FSJD3023-00Z
FINDER ASSY
1
19 FSXP2035-108
PRESET BUTTON
1
1-6,DISP,SCAN/RT
20 FSYH4036-031
SHEET
1
21 FSXP3053-002
POWER BUTTON
1
22 FSXP3054-002
EJECT BUTTON
1
23 FSXP2034-034
D.FUNC BUTTON
1
CD/FM/AM
24 FSXP4005-029
BBE BUTTON
1
SCM
25 FSXP3068-001
PUSH BUTTON
1
LOUD,MO/RND
26 FSXP2044-001
COMBO BUTTON
1
27 FSXP3055-001
DETACH BUTTON
1
28 FSKW3002-012
COMP. SPRING
1
DETACH BUTTON
29 FSJK3026-001
CD LENS
1
30 FSJC1043-002
REAR COVER
1
31 VKZ4777-001
MINI SCREW
4
FRONT+REAR
32 GE30320-001A
NAME PLATE
1
33 QMFZ047-100-T
FUSE
A
1
34 VMA4652-001SS
EARTH PLATE
1
35 FSYH3023-001
LCD CASE
1
36 FSJK3035-001
LCD LENS
1
37 FSKS3022-002
LENS CASE
1
38 FSYH4078-001
LIGHTING SHEET
1
39 QNZ0442-001
RUBBER CONNE
1
41 FSKM3010-013
REAR BRACKET
1
42 FSKL4018-00B
IC BRACKET
1
43 GE40104-002B
HEAT SINK
1
44 GE40103-001A
REGULATOR BKT
1
45 QYSDST2606Z
SCREW
1
FOR ANT
46 QYSDST2606Z
SCREW
3
16P&TR BRACKET
LCD 1 QLD0161-002
LCD
1
