JVC KD-S50 - Page 40

KD-S50
3-6
Item
Parts number Parts name Area
A
Parts list (CD mechanism)
Q'ty
Description
Block No. MBMM
71 64180403T
DET SWITCH
2
ESE22MH3
72 68150232T
CONNECTOR
1
TKC-W26X-C1
79 30311105T
SOPPORT PLATE
1
80 30311138T
GR MT BLK(N)
1
81 30311109T
LDG GEAR (2)
1
82 30311110T
LDG GEAR (3)
1
84 30311112T
LDG GEAR (5)
1
86 30311136T
LDG ROLLER
2
88 30311118T
L.P SPRING (L)
1
89 30311119T
L.P SPRING (R)
1
90 30311123T
SW PCB
1
91 30311124T
SW ACTUATOR
1
92 30311129T
LDG BELT
1
93 30311140T
FRONT BRKT (J)
1
100 9C0620503T
C B TAP SCREW
2
M2X5
101 9C2020401T
C SCREW TS.G
5
M2X4
102 9C4320403T
C B TAP SCREW
4
M2X4
103 9C0117223T
SCREW
2
M1.7X2.2
104 9C0917703T
C TAP SCREW S3
1
M1.7X7
105 9C0320201T
C TAP SCREW S3
1
M2X2
106 9C4920013T
C TAP SCREW S3
2
M2X10
107 9C4920603T
C TAP SCREW B3
4
M2X6
108 9P0220031T
TAMS SCREW
2
M2X3
109 9C0314203T
C TAP SCREW
1
M1.4X2
110 9C0420253
C TAP SCREW
1
M2X2.5
113 9W0330276
NW BLUE
2
2.9X5X0.3
116 9W0725030T
LUMILAR W
1
2.3X9.8X0.25
117 9W0640030T
WASHER
1
1.4X3.2X0.4
130 303105310T
FEED MO ASSY
1
131 303105311T
SPINDLE MO ASSY
1
132 303105312T
FEED SCREW ASSY
1
133 303111301T
LDG MOTOR ASSY
1
134 303111302T
RDG RLR SFT ASY
1
135 303105502T
T.T.BASE ASSY
1
