JVC KD-S50 - Page 43

KD-S50
3-9
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
R 563 NRSA63J-102X MG RESISTOR
R 564 NRSA63J-102X MG RESISTOR
R 567 NRSA63J-102X MG RESISTOR
R 568 NRSA63J-102X MG RESISTOR
R 569 NRSA63J-102X MG RESISTOR
R 570 NRSA63J-102X MG RESISTOR
R 571 NRS181J-333X MG RESISTOR
R 573 NRSA63J-333X MG RESISTOR
R 574 NRSA63J-221X MG RESISTOR
R 575 NRSA63J-221X MG RESISTOR
R 576 NRSA63J-0R0X MG RESISTOR
R 577 NRSA63J-104X MG RESISTOR
R 579 NRSA63J-102X MG RESISTOR
R 580 NRSA63J-224X MG RESISTOR
R 581 NRSA63J-0R0X MG RESISTOR
R 701 NRSA63J-102X MG RESISTOR
R 702 NRSA63J-0R0X MG RESISTOR
R 703 NRSA63J-102X MG RESISTOR
R 704 NRSA63J-0R0X MG RESISTOR
R 705 NRSA63J-103X MG RESISTOR
R 708 NRSA63J-822X MG RESISTOR
R 725 NRSA63J-820X MG RESISTOR
R 731 NRS181J-152X MG RESISTOR
R 732 NRSA63J-102X MG RESISTOR
R 733 NRSA63J-103X MG RESISTOR
R 734 NRS181J-471X MG RESISTOR
R 791 NRSA63J-103X MG RESISTOR
R 792 NRSA63J-102X MG RESISTOR
R 793 NRSA63J-103X MG RESISTOR
R 794 NRSA63J-222X MG RESISTOR
R 795 NRS181J-150X MG RESISTOR
R 796 NRS181J-150X MG RESISTOR
R 797 NRS181J-100X MG RESISTOR
R 798 NRSA63J-223X MG RESISTOR
R 799 NRSA63J-473X MG RESISTOR
R 801 NRS181J-103X MG RESISTOR
R 803 NRS181J-332X MG RESISTOR
R 804 NRS181J-332X MG RESISTOR
R 805 NRS181J-332X MG RESISTOR
R 807 NRS181J-473X MG RESISTOR
R 808 NRS181J-102X MG RESISTOR
R 809 NRS181J-103X MG RESISTOR
R 810 NRSA63J-104X MG RESISTOR
R 811 NRSA63J-332X MG RESISTOR
R 812 NRSA63J-332X MG RESISTOR
R 813 NRSA63J-473X MG RESISTOR
R 814 NRSA63J-473X MG RESISTOR
R 815 NRSA63J-473X MG RESISTOR
R 816 NRSA63J-473X MG RESISTOR
R 817 NRS181J-472X MG RESISTOR
R 818 NRS181J-473X MG RESISTOR
R 822 NRSA63J-222X MG RESISTOR
R 823 NRSA63J-473X MG RESISTOR
R 825 NRS181J-473X MG RESISTOR
R 826 NRSA63J-473X MG RESISTOR
R 827 NRSA63J-473X MG RESISTOR
R 828 NRSA63J-473X MG RESISTOR
R 829 NRS181J-473X MG RESISTOR
R 830 NRS181J-223X MG RESISTOR
R 831 NRS181J-472X MG RESISTOR
R 832 NRS181J-223X MG RESISTOR
R 833 NRS181J-472X MG RESISTOR
R 834 NRS181J-223X MG RESISTOR
R 835 NRS181J-472X MG RESISTOR
R 836 NRSA63J-473X MG RESISTOR
R 840 NRSA63J-473X MG RESISTOR
R 841 NRSA63J-473X MG RESISTOR
R 842 NRSA63J-473X MG RESISTOR
R 843 NRSA63J-0R0X MG RESISTOR
R 844 NRSA63J-0R0X MG RESISTOR
R 845 NRSA63J-0R0X MG RESISTOR
R 861 NRS181J-471X MG RESISTOR
R 862 NRS181J-471X MG RESISTOR
R 902 QRZ0125-472X C RESISTOR 4.7K 1/4W
R 903 NRSA63J-202X MG RESISTOR
R 904 NRSA63J-104X MG RESISTOR
R 905 NRSA63J-472X MG RESISTOR
R 906 NRSA63J-472X MG RESISTOR
R 907 NRSA63J-393X MG RESISTOR
R 908 NRSA63J-683X MG RESISTOR
R 909 NRSA63J-273X MG RESISTOR
R 910 NRSA63J-473X MG RESISTOR
R 911 NRS181J-473X MG RESISTOR
TU701 QAU0257-001 TUNER
X 561 QAX0714-001Z C RESONATOR
X 801 QAX0406-001Z CRYSTAL
