JVC KD-S51 Service Manual

3-11
CD mechanism control board
Block No. [0][3]

Symbol
No.
Part No. Part Name Description Local
IC501 TMP91CW12AF5VD9 IC S51J
IC501 TMP91CW12AF5VD9 IC
IC502 BR24L01AFV-W-X IC S51J
IC502 BR24L01AFV-W-X IC
IC503 SN74AHCT126PW-X IC(DIGITAL) S51J
IC503 SN74AHCT126PW-X IC(DIGITAL)
IC504 NJU7241F33-X IC S51J
IC504 NJU7241F33-X IC
IC571 PCM1753-X IC S51J
IC571 PCM1753-X IC
IC572 NJM4580V-X IC S51J
IC572 NJM4580V-X IC
IC573 SN74AHCU04PW-X IC S51J
IC573 SN74AHCU04PW-X IC
IC601 TA2157FN-X RF AMP IC S51J
IC601 TA2157FN-X RF AMP IC
IC621 TC94A14FA CD LSI IC S51J
IC621 TC94A14FA CD LSI IC
IC651 NJU7772F15-X IC S51J
IC651 NJU7772F15-X IC
IC652 TC94A34FG-002 IC S51J
IC652 TC94A34FG-002 IC
IC681 BA5830FP-X IC S51J
IC681 BA5830FP-X IC
Q501 UN2111-X TRANSISTOR S51J
Q501 UN2111-X TRANSISTOR
Q502 UN2211-X TRANSISTOR S51J
Q502 UN2211-X TRANSISTOR
Q571 UN2111-X TRANSISTOR S51J
Q571 UN2111-X TRANSISTOR
Q572 UN2211-X TRANSISTOR S51J
Q572 UN2211-X TRANSISTOR
Q573 2SB624/4/-X TRANSISTOR S51J
Q573 2SB624/4/-X TRANSISTOR
Q574 UN2211-X TRANSISTOR S51J
Q574 UN2211-X TRANSISTOR
Q601 2SB1132/QR/-W TRANSISTOR S51J
Q601 2SB1132/QR/-W TRANSISTOR
Q651 2SB624/4/-X TRANSISTOR S51J
Q651 2SB624/4/-X TRANSISTOR
Q652 UN2211-X TRANSISTOR S51J
Q652 UN2211-X TRANSISTOR
Q681 2SB1184/QR/-X TRANSISTOR S51J
Q681 2SB1184/QR/-X TRANSISTOR
D506 MA111-X SI DIODE S51J
D506 MA111-X SI DIODE
D682 1SR154-400-X DIODE S51J
D682 1SR154-400-X DIODE
C501 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C501 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C503 NEAG0JM-107X E CAPACITOR 100uF 6.3V M S51J
C503 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C504 NDC31HJ-220X C CAPACITOR 22pF 50V J S51J
C504 NDC31HJ-220X C CAPACITOR 22pF 50V J
C505 NDC31HJ-220X C CAPACITOR 22pF 50V J S51J
C505 NDC31HJ-220X C CAPACITOR 22pF 50V J
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C508 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C508 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C509 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C509 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C510 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C510 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB31CK-104X C CAPACITOR 0.1uF 16V K S51J
C511 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C512 NEAG0JM-107X E CAPACITOR 100uF 6.3V M S51J
C512 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C513 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C514 NCS31HJ-102X C CAPACITOR 1000pF 50V J S51J
C514 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C551 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C551 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C561 NCB31EK-123X C CAPACITOR 0.012uF 25V K S51J
C561 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C571 NDC31HJ-270X C CAPACITOR 27pF 50V J S51J
C571 NDC31HJ-270X C CAPACITOR 27pF 50V J
C572 NDC31HJ-270X C CAPACITOR 27pF 50V J S51J
C572 NDC31HJ-270X C CAPACITOR 27pF 50V J
C573 NCB31CK-104X C CAPACITOR 0.1uF 16V K S51J
C573 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C574 NEAG0JM-107X E CAPACITOR 100uF 6.3V M S51J
C574 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C575 NEAG0JM-107X E CAPACITOR 100uF 6.3V M S51J
C575 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C577 NCB31CK-104X C CAPACITOR 0.1uF 16V K S51J
C577 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C578 NEAG0JM-107X E CAPACITOR 100uF 6.3V M S51J
C578 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C580 NCB31EK-123X C CAPACITOR 0.012uF 25V K S51J
C580 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C581 NDC31HJ-101X C CAPACITOR 100pF 50V J S51J
C581 NDC31HJ-101X C CAPACITOR 100pF 50V J
C582 NDC31HJ-101X C CAPACITOR 100pF 50V J S51J
C582 NDC31HJ-101X C CAPACITOR 100pF 50V J
C583 NCS31HJ-821X C CAPACITOR 820pF 50V J S51J
C583 NCS31HJ-821X C CAPACITOR 820pF 50V J
C584 NCS31HJ-821X C CAPACITOR 820pF 50V J S51J
C584 NCS31HJ-821X C CAPACITOR 820pF 50V J
C585 NEAG1VM-475X E CAPACITOR 4.7uF 35V M S51J
C585 NEAG1VM-475X E CAPACITOR 4.7uF 35V M
C586 NEAG1VM-475X E CAPACITOR 4.7uF 35V M S51J
C586 NEAG1VM-475X E CAPACITOR 4.7uF 35V M
C587 NDC31HJ-151X C CAPACITOR 150pF 50V J S51J
C587 NDC31HJ-151X C CAPACITOR 150pF 50V J
C588 NDC31HJ-151X C CAPACITOR 150pF 50V J S51J
C588 NDC31HJ-151X C CAPACITOR 150pF 50V J
C589 NEAG1VM-475X E CAPACITOR 4.7uF 35V M S51J
C589 NEAG1VM-475X E CAPACITOR 4.7uF 35V M
C590 NEAG1VM-475X E CAPACITOR 4.7uF 35V M S51J
C590 NEAG1VM-475X E CAPACITOR 4.7uF 35V M
C591 NEAG0JM-476X E CAPACITOR 47uF 6.3V M S51J
C591 NEAG0JM-476X E CAPACITOR 47uF 6.3V M
C592 NEAG0JM-476X E CAPACITOR 47uF 6.3V M S51J
C592 NEAG0JM-476X E CAPACITOR 47uF 6.3V M
C593 NEAG1CM-476X E CAPACITOR 47uF 16V M S51J
C593 NEAG1CM-476X E CAPACITOR 47uF 16V M
C594 NCS31HJ-102X C CAPACITOR 1000pF 50V J S51J
C594 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C595 NCB31CK-473X C CAPACITOR 0.047uF 16V K S51J
C595 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C596 NDC31HJ-101X C CAPACITOR 100pF 50V J S51J
C596 NDC31HJ-101X C CAPACITOR 100pF 50V J
C597 NCS31HJ-102X C CAPACITOR 1000pF 50V J S51J
C597 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C598 NCS31HJ-102X C CAPACITOR 1000pF 50V J S51J
C598 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C601 NEAG0JM-476X E CAPACITOR 47uF 6.3V M S51J
C601 NEAG0JM-476X E CAPACITOR 47uF 6.3V M
C602 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C602 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C603 NEAG0JM-107X E CAPACITOR 100uF 6.3V M S51J
C603 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C604 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C604 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C605 NCB31HK-682X C CAPACITOR 6800pF 50V K S51J
C605 NCB31HK-682X C CAPACITOR 6800pF 50V K
C606 NEAG0JM-476X E CAPACITOR 47uF 6.3V M S51J
C606 NEAG0JM-476X E CAPACITOR 47uF 6.3V M
C607 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C607 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C608 NCB31CK-104X C CAPACITOR 0.1uF 16V K S51J

Symbol
No.
Part No. Part Name Description Local
