KD-S587
3-10
Item
Parts number Parts name Ar
Remarks
A
C 601 NCB31HK-223X C CAPACITOR
C 602 NCS31HJ-681X C CAPACITOR
C 603 NBE20JM-106X TS E CAP SVB20J
C 611 NCB31HK-123X C CAPACITOR
C 612 NBE20JM-475X TS E CAPACITOR
CJ601 VMC0335-001 CONNECTOR
D 601 SML-310VT/JK/-X LED VOL+ R LED
D 602 SML-310VT/JK/-X LED VOL- R LED
D 603 SML-310VT/JK/-X LED LOUD R LED
D 604 SML-310VT/JK/-X LED SEL R LED
D 605 SML-310VT/JK/-X LED DISP R LED
D 606 SML-310VT/JK/-X LED 1 R LED
D 607 SML-310VT/JK/-X LED 2 R LED
D 608 SML-310VT/JK/-X LED 3 R LED
D 609 SML-310VT/JK/-X LED 4 R LED
D 610 SML-310VT/JK/-X LED 5 R LED
D 611 SML-310VT/JK/-X LED 6 R LED
D 612 SML-310VT/JK/-X LED MODE R LED
D 613 LT1F67AF-W LED SCM G LED
D 614 SML-310VT/JK/-X LED EJECT R LED
D 615 SML-310VT/JK/-X LED FM R LED
D 616 SML-310VT/JK/-X LED CD R LED
D 617 SML-310VT/JK/-X LED AM R LED
D 618 SML-310VT/JK/-X LED UP R LED
D 619 SML-310VT/JK/-X LED DOWN R LED
D 620 SML-310LT/MN/-X LED POWER R LED
D 641 UDZS5.1B-X Z DIODE
D 642 1SS355-X DIODE
D 643 1SS355-X DIODE
D 644 UDZS5.1B-X Z DIODE
D 645 UDZS6.2B-X SI DIODE
IC601 LC75823W IC
IC602 RPM6938-SV4 IC
PL601 QLL0033-003 LAMP
PL602 QLL0033-003 LAMP
R 601 NRSA63J-681X MG RESISTOR
R 602 NRSA63J-561X MG RESISTOR
R 603 NRSA63J-681X MG RESISTOR
R 604 NRSA63J-911X MG RESISTOR
R 605 NRSA63J-122X MG RESISTOR
R 606 NRSA02J-681X MG RESISTOR
R 607 NRSA02J-561X MG RESISTOR
R 608 NRSA02J-681X MG RESISTOR
R 609 NRSA02J-911X MG RESISTOR
R 610 NRSA63J-122X MG RESISTOR
R 611 NRSA63J-152X MG RESISTOR
R 612 NRSA63J-681X MG RESISTOR
R 613 NRSA63J-561X MG RESISTOR
R 614 NRSA63J-681X MG RESISTOR
R 615 NRSA63J-911X MG RESISTOR
R 616 NRSA63J-122X MG RESISTOR
R 617 NRSA63J-152X MG RESISTOR
R 631 NRSA02J-821X MG RESISTOR
R 632 NRSA02J-222X MG RESISTOR
R 633 NRSA02J-222X MG RESISTOR
R 634 NRSA02J-102X MG RESISTOR
R 635 NRSA02J-102X MG RESISTOR
R 636 NRSA02J-122X MG RESISTOR
R 637 NRSA02J-122X MG RESISTOR
R 638 NRSA02J-391X MG RESISTOR
R 639 NRSA02J-391X MG RESISTOR
R 640 NRSA02J-391X MG RESISTOR
R 641 NRSA02J-391X MG RESISTOR
R 642 NRSA02J-681X MG RESISTOR
R 643 NRSA02J-681X MG RESISTOR
R 644 NRSA02J-102X MG RESISTOR
R 645 NRSA02J-102X MG RESISTOR
R 651 NRSA63J-222X MG RESISTOR
R 652 NRSA63J-222X MG RESISTOR
R 653 NRSA63J-103X MG RESISTOR
R 654 NRSA63J-103X MG RESISTOR
R 655 NRSA63J-103X MG RESISTOR
R 656 NRSA63J-103X MG RESISTOR
R 657 NRSA63J-513X MG RESISTOR
R 658 NRSA63J-184X MG RESISTOR
R 661 NRSA63J-103X MG RESISTOR
R 662 NRSA63J-471X MG RESISTOR
S 601 NSW0066-001X TACT SWITCH POWER
S 602 NSW0066-001X TACT SWITCH VOL-
S 603 NSW0066-001X TACT SWITCH VOL+
S 604 NSW0066-001X TACT SWITCH LOUD
S 605 NSW0066-001X TACT SWITCH DISP
S 606 NSW0066-001X TACT SWITCH 1
S 607 NSW0066-001X TACT SWITCH SELECT
S 608 NSW0066-001X TACT SWITCH 2
S 609 NSW0066-001X TACT SWITCH 3
S 610 NSW0066-001X TACT SWITCH 4
S 611 NSW0066-001X TACT SWITCH 5
S 612 NSW0066-001X TACT SWITCH EJECT
S 613 NSW0066-001X TACT SWITCH UP
S 614 NSW0066-001X TACT SWITCH 6
S 615 NSW0066-001X TACT SWITCH MODE
S 616 NSW0066-001X TACT SWITCH SCM
S 617 NSW0066-001X TACT SWITCH DOWN
S 618 NSW0066-001X TACT SWITCH AM
S 619 NSW0066-001X TACT SWITCH FM
S 620 NSW0066-001X TACT SWITCH CD
Electrical parts list (Front board)
Block No. 02
