KD-S595
3-8
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
C 906 NCB31EK-104X C CAPACITOR
C 907 NCB31HK-103X C CAPACITOR
C 908 QERF1AM-107Z E CAPACITOR
100MF 20% 10V
C 909 QERF1AM-107Z E CAPACITOR
100MF 20% 10V
C 910 NCB31HK-103X C CAPACITOR
C 911 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
C 914 NCB31EK-104X C CAPACITOR
C 915 NCB11CK-225X C CAPACITOR
C 916 QERF1HM-225Z E CAPACITOR
2.2MF 20% 50V
CJ321 QNN0519-001 PIN JACK
SILVER
CJ701 QNB0100-002 ANT TERMINAL
CN501 QGB2027M4-22S CONNECTOR
CN801 VMC0334-001 CONNECTOR
CN901 QNZ0611-001 CAR CONNECTOR
D 321 1SS133-T2 SI DIODE
D 332 1SS355-X DIODE
D 333 1SS355-X DIODE
D 551 1A3G-T1 SI DIODE
D 701 1SS133-T2 SI DIODE
D 702 1SS133-T2 SI DIODE
D 731 MTZJ10B-T2 ZENER DIODE
D 791 1SS355-X DIODE
D 792 1SS355-X DIODE
D 801 1SS133-T2 SI DIODE
D 810 1SS355-X DIODE
D 821 UDZS6.2B-X SI DIODE
D 822 UDZS6.2B-X SI DIODE
D 823 UDZS6.2B-X SI DIODE
D 824 UDZS6.2B-X SI DIODE
D 825 UDZS6.2B-X SI DIODE
D 826 UDZS6.2B-X SI DIODE
D 827 UDZS6.2B-X SI DIODE
D 828 UDZS6.2B-X SI DIODE
D 861 MTZJ4.7B-T2 Z DIODE
D 866 1SS355-X DIODE
D 867 1SS355-X DIODE
D 868 1SS355-X DIODE
D 869 1SS355-X DIODE
D 901 1N5401-F64 DIODE
D 903 1SS133-T2 SI DIODE
D 904 RB160M-30-X SB DIODE
D 905 RB160M-30-X SB DIODE
IC151 NJM4565M-WE IC
IC301 TEA6320T-X IC
IC321 LA4743K IC
IC501 AN8806SB-W IC
IC541 LA6589H-X IC
IC561 MN6627482WA IC
IC801 JES01-9B42 I.C(MONO-OTHER)
IC901 HA13164A IC
L 501 QQL231K-4R7Y INDUCTOR
L 561 QQL231K-4R7Y INDUCTOR
L 562 QQL231K-4R7Y INDUCTOR
L 701 QQL231K-4R7Y INDUCTOR
L 801 QQL231K-4R7Y INDUCTOR
L 901 QQR0703-001 CHOKE COIL
321 UN2211-X TRANSISTOR
332 2SD1781K/QR/-X TRANSISTOR
432 2SD1781K/QR/-X TRANSISTOR
501 2SA1706/ST/-T TRANSISTOR
541 2SA1706/ST/-T TRANSISTOR
701 UN2211-X TRANSISTOR
731 2SC1623/5-6/-X TRANSISTOR
732 2SC1623/5-6/-X TRANSISTOR
791 2SB1197K/QR/-X TRANSISTOR
792 2SA812/5-6/-X TRANSISTOR
793 UN2211-X TRANSISTOR
861 UN2111-X TRANSISTOR
902 2SC1623/5-6/-X TRANSISTOR
903 2SA812/5-6/-X TRANSISTOR
R 101 NRSA63J-471X MG RESISTOR
R 102 NRSA63J-752X MG RESISTOR
R 151 NRSA63J-183X MG RESISTOR
R 152 NRSA63J-123X MG RESISTOR
R 153 NRSA63J-273X MG RESISTOR
R 154 NRSA63J-223X MG RESISTOR
R 155 NRSA63J-152X MG RESISTOR
R 156 NRS181J-223X MG RESISTOR
R 201 NRSA63J-471X MG RESISTOR
R 202 NRSA63J-752X MG RESISTOR
R 251 NRSA63J-183X MG RESISTOR
R 252 NRSA63J-123X MG RESISTOR
R 253 NRSA63J-273X MG RESISTOR
R 254 NRSA63J-223X MG RESISTOR
R 255 NRSA63J-152X MG RESISTOR
R 256 NRS181J-223X MG RESISTOR
R 301 NRSA63J-223X MG RESISTOR
R 302 NRSA63J-222X MG RESISTOR
R 303 NRSA63J-473X MG RESISTOR
R 304 NRSA63J-473X MG RESISTOR
R 307 NRSA63J-273X MG RESISTOR
R 308 NRSA63J-273X MG RESISTOR
R 321 NRSA63J-473X MG RESISTOR
R 322 NRSA63J-471X MG RESISTOR
R 323 NRSA63J-102X MG RESISTOR
R 333 NRSA63J-102X MG RESISTOR
R 334 NRSA63J-101X MG RESISTOR
R 336 NRSA63J-222X MG RESISTOR
R 401 NRSA63J-223X MG RESISTOR
R 402 NRSA63J-222X MG RESISTOR
R 403 NRSA63J-473X MG RESISTOR
R 404 NRSA63J-473X MG RESISTOR
R 407 NRSA63J-273X MG RESISTOR
R 408 NRSA63J-273X MG RESISTOR
R 433 NRSA63J-102X MG RESISTOR
R 434 NRSA63J-101X MG RESISTOR
R 436 NRSA63J-222X MG RESISTOR
R 501 NRSA02J-220X MG RESISTOR
R 502 NRSA02J-220X MG RESISTOR
R 503 NRS181J-102X MG RESISTOR
R 504 NRSA63J-202X MG RESISTOR
R 505 NRSA63J-224X MG RESISTOR
R 506 NRSA63J-223X MG RESISTOR
R 507 NRSA63J-822X MG RESISTOR
R 508 NRSA63J-393X MG RESISTOR
R 509 NRSA63J-153X MG RESISTOR
R 510 NRSA63J-154X MG RESISTOR
R 511 NRSA63J-274X MG RESISTOR
R 512 NRSA63J-563X MG RESISTOR
R 513 NRSA63J-563X MG RESISTOR
R 516 NRSA63J-123X MG RESISTOR
R 517 NRSA63J-123X MG RESISTOR
R 518 NRSA63J-822X MG RESISTOR
R 519 NRSA63J-105X MG RESISTOR
R 524 NRSA63J-202X MG RESISTOR
R 525 NRS181J-911X MG RESISTOR
R 541 NRS181J-682X MG RESISTOR
R 542 NRSA63J-561X MG RESISTOR
R 543 NRSA63J-473X MG RESISTOR
R 544 NRSA63J-512X MG RESISTOR
R 545 NRSA63J-332X MG RESISTOR
R 546 NRSA63J-123X MG RESISTOR
