KS-FX230

1-19

1 2 3 4 5 6 7 8 9

GND OUT1 P1

VZ IN1 IN2

VCC1

VCC2 P2

OUT2

Input Output

Mode

IN1 IN2 OUT1 OUT2

Brake

0 0 0 0

1 0 1 0

0 1 0 1

1 1 0 0

CLOCKWISE

COUNTER-CLOCKWISE

Brake

LB1641 (IC501) : DC motor driver

1. Pin layout

2. Pin functions

1.Block diagram and pin configuration

CXA2509AQ(IC901):Cassette mecha controler
