Audio Settings
KD-X282BT:
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
[REAR/REAR] Rear speakers output
[REAR/SUB.W] (default) Subwoofer output
[SUB.W/SUB.W] Subwoofer output
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page31)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
[REAR/REAR] Rear speakers output Rear speakers output
[REAR/SUB.W] Rear speakers output Rear speakers output
[SUB.W/SUB.W] Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[120HZ] is selected in [SUBWOOFERLPF] and [THROUGH] is not available.
(Page22)
–
[POSITION R02] is selected in [FADER] and selectable range is [POSITION R15] to
[POSITION 00] . (Page19)
Crossover settings
Below are the available setting items for 2-way crossover and 3-way
crossover.
CAUTION
Select a crossover type according to how the speakers are connected.
(Page31)
If you select a wrong type:
• The speakers may be damaged.
• The output sound level may be extremely high or low.
SPEAKER SIZE
Selects according to the connected speaker size for optimum performance.
• The frequency and slope settings are automatically set for the crossover of
the selected speaker.
• If
[NONE] is selected for the following speaker in [SPEAKER SIZE] , the [X ‘ OVER]
setting of the selected speaker is not available.
– 2-way crossover:
[TWEETER] of [FRONT] / [REAR] / [SUBWOOFER]
– 3-way crossover: [WOOFER]
X ‘ OVER (crossover)
•
[FRQ] / [F-HPFFRQ] / [R-HPFFRQ] / [SWLPF FRQ] / [HPFFRQ] / [LPFFRQ] : Adjusts the
crossover frequency for the selected speakers (high pass filter or low pass
filter).
If
[THROUGH] is selected, all signals are sent to the selected speakers.
•
[SLOPE] / [F-HPFSLOPE] / [R-HPFSLOPE] / [SWLPF SLOPE] / [HPFSLOPE] / [LPFSLOPE] :
Adjusts the crossover slope.
Selectable only if a setting other than
[THROUGH] is selected for the
crossover frequency.
•
[SW LPF PHASE] / [PHASE] : Selects the phase of the speaker output to be in line
with the other speaker output.
•
[GAINLEFT] / [GAINRIGHT] / [F-HPFGAIN] / [R-HPFGAIN] / [SWLPF GAIN] / [GAIN] : Adjusts
the output volume of the selected speaker.
KD-X382BT_E_B5A-3841-00_EN_1st Draft.indd 21KD-X382BT_E_B5A-3841-00_EN_1st Draft.indd 21 17/9/2021 11:32:08 PM17/9/2021 11:32:08 PM
