(No.YA180)3-3
EXPLODED VIEW PARTS LIST -1
Ref.No. Part No. Part Name Description Local
101 LC11992-001B-0K JACK COVER (x2)
102 LC32830-001A-A RATING LABEL
103 LC32748-002B-H OPERATION SHEET
104 LC32749-002A-H OPERATION SHEET
105 LC41999-005A-A CAUTION LABEL
106 LC41424-001A-A HDCP WARNING
107 LC41967-001C-C STAND ASSY Inc.107A-107B LT-32X575/KA
107 LC41967-002A-C STAND ASSY Inc.107A-107B LT-32X585/KA
107A 128-023 STAND COVER
107B 128-020 CORD COVER
108 QYSPSPD5014M SCREW M5 x 14mm(x4)
109 QYSPSPD3016Z SCREW M3 x 16mm(x2)
110 LC42002-002B-C STAND SHEET LT-32X575/KA
110 LC42002-003A STAND SHEET LT-32X585/KA
111 LC11991-001A-0K REAR COVER LT-32X575/KA
111 LC11991-002A-0K REAR COVER LT-32X585/KA
112 QYSBSFG4016M TAP SCREW M4 x 16mm(x7)
113 QYSBSF3010M TAP SCREW M3 x 10mm(x4)
114 QYSPSPD3008M SCREW M3 x 8mm
115 LC32760-001A-HK SERVICE COVER
116 QYSBSF3010M TAP SCREW M3 x 10mm
117 QMPD460-170-JC POWER CORD(US/CA) 1.7m BLACK
118 LC21348-001D-HK POWER CORD HOLDER
119 LC21596-002B-HK TERMINAL BASE
120 LC32351-008A-0K CONTROL KNOB ASSY LT-32X575/KA
120 LC32351-009A-0K CONTROL KNOB ASSY LT-32X585/KA
121 LC32698-002B-HK CARD BASE LT-32X575/KA
121 LC32698-003B-HK CARD BASE LT-32X585/KA
122 LC21597-002C-HK TUNER BASE LT-32X575/KA
122 LC21597-002B-HK TUNER BASE LT-32X585/KA
123 QUB190-12FXHM SIN TWIST WIRE
124 QLD0338-001 LCD PANEL UNIT
125 LC11633-001B-0K SPEAKER BOX
126 QAS0142-001 SPEAKER SP01/SP02(x2)
127 LC42001-002B-C DUCT SHEET (x2)
128 LC21339-001A-HK DUCT BASE (x2)
129 LC21340-001B-HK DUCT COVER (x2)
130 LC11988-004B-0K FRONT PANEL ASSY LT-32X575/KA
130 LC11988-003B-0K FRONT PANEL ASSY LT-32X585/KA
131 LC41901-001C-HK LED LENS
132 LC32747-001C-HK SENSOR WINDOW
133 CM48006-010-C JVC MARK LT-32X575/KA
133 CM48006-008-C JVC MARK LT-32X585/KA
134 LC32864-001A-C STICK SHEET (x2)
135 QUQ105-3004AA FFC WIRE 30pin 4cm
136 QUQ105-5004AA FFC WIRE 50pin 4cm
137 QUQ105-4006AL FFC WIRE 40pin 6cm
138 QUQ105-5009AE FFC WIRE 50pin 9cm
139 QUQ212-1906CH FFC WIRE 19pin 6cm
140 LC40822-002A-A WARNING LABEL
201 SFL-9105A-M2 REGULATOR PWB
202 SFL-9005A-M2 POWER PWB
203 SFL0F101A-M2 RECEIVER PWB
204 SFL-4011A-M2 CONNECTOR PWB
205 SFL-1012A-M2 ANALOG SIGNAL PWB
206 SFL-7011A-M2 FRONT CONTROL PWB
207 SFL-8011A-M2 FRONT SENSOR PWB
208 SFL0D105A-M2 DIGITAL SIGNAL PWB LT-32X575/KA
208 SFL0D104A-M2 DIGITAL SIGNAL PWB LT-32X585/KA
To Next Page
