JVC MX-J50 - Proper Ventilation Guidelines; Apparatus Placement for Ventilation

CA-D3SCA-D3S
1 cm1 cm
15 cm 15 cm
15 cm 15 cm
15 cm
10 cm
Front view
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent
damage, locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No obstructions should be placed in the areas shown by
the dimensions below.
3 Bottom:
Place on the level surface. Maintain an adequate air
path for ventilation by placing on a stand with a height of
10 cm (3
15
/16 in.) or more.
CA-MXJ50
CA-MXJ50
– G-2 –
10 cm
(3
15
/16 in.)
1 cm
(
7
/16 in.)
1 cm
(
7
/16 in.)
15 cm
(5
15
/16 in.)
15 cm
(5
15
/16 in.)
15 cm
(5
15
/16 in.)
15 cm
(5
15
/16 in.)
15 cm
(5
15
/16 in.)
Side view
