MX-J570V/MX-J680V
3-2
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
1 GV10027-002A FRONT PANEL 1 MX-J570V
GV10027-004A FRONT PANEL 1 MX-J680V
2 E75896-001 FELT SPACER 2
3 GV40077-001A JVC BADGE 1
4 GV40080-001A STBY.INDICATOR 1
5 GV20056-001A CD EJECT BUTTON 1
6 GV20057-002A CD BUTTON 1
7 GV30087-001A POWER BUTTON 1 ON/STANDBY MARK
8 GV30088-001A PUSH BUTTON 1
9 GV20049-004A SOURCE BUTTON(A) 1 CD/TUNER MARK
10 GV20050-002A SOURCE BUTTON(B) 1 TAPE/AUX MARK
11 QYSDSF2608Z SCREW 2 POWER BOARD
12 QYSDSF2608Z SCREW 1 REMOTE SENSOR
13 QYSDSF2608Z SCREW 4 STY.BKT+F.PANEL
14 GV30082-001A STAY BRACKET 1
15 QYSDSF2608Z SCREW 4 CD SWITCH BOARD
16 QYSDSF2608Z SCREW 2 VOLUME BOARD
17 QYSDSF2608Z SCREW 2 CD/TUNER S.BOARD
18 QYSDSF2608Z SCREW 2 TAPE/AUX S.BOARD
19 FMYH4004-001 PLASTIC RIVET 2 TRANS.SHD/P.BOARD
20 GV10029-002A CASS.HOLDER(L) 1 MX-J680V
GV10029-001A CASS.HOLDER(L) 1 MX-J570V
21 GV10030-001A CASS.HOLDER(R) 1 MX-J570V
GV10030-002A CASS.HOLDER(R) 1 MX-J680V
22 GV20053-001A CASS LENS (L) 1
23 GV20054-001A CASS LENS (R) 1
24 GV30077-001A EJECT BUTTON(A) 1
25 GV30078-001A EJECT BUTTON(B) 1
26 FMKW4009-002 HOLDER SPRING(A) 1
27 FMKW4010-002 HOLDER SPRING(B) 1
28 FMKW4011-001 SPRING 1 FOR EJECT LEVER
29 FMKS3002-003 EJECT LEVER(A) 1
30 FMKS3003-003 EJECT LEVER(B) 1
31 GV40034-001A DAMPER ASSY 2
32 VKY4180-401 CASSETTE SPRING 4
33 GV10014-005A CASE ASSY 1
34 MXN-13FB12F DC MOTOR 1
35 GV40022-001A MOTOR PULLEY 1
36 GV30038-001A CAPSTAN BELT 1
37 GV30086-009A MOVING PANEL(A) 1 MX-J680V
GV30086-007A MOVING PANEL(A) 1 MX-J570V
38 GV30089-001A PANEL PLATE 1
39 GV20058-003A CONTROL BUTTON 1
40 QYSDSF2608Z SCREW 2
41 GV30042-002A PANEL BRACKET 1
42 GV40028-001A PANEL HOLDER(L) 1
43 GV40028-002A PANEL HOLDER(R) 1
44 QYSDSF2608Z SCREW 4 S.BRD./C.BTN.ASS'Y
Exploded view of general assembly and parts list
To Next Page
