3-3
MX-J570V/MX-J680V
スミ 金赤 青
2‑9 あお 2‑9 あか 2‑9 すみ
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
45 GV20059-002A MOVING PANEL(B) 1 MX-J680V
GV20059-001A MOVING PANEL(B) 1 MX-J570V
46 QYSBST2606Z T.SCREW 3 M.PNL B/PNL BKT
47 VKZ4341-204 SPECIAL SCREW 2 ARM CASE/PNL BKT
48 QYSDSF2608Z SCREW 2 FL BOARD / CASE
49 QYSSSF3012Z TAP SCREW 4 MOVING PNL./F.P
50 --------------- CASSETTE MECHA 1
51 FMKL4012-004 EJECT SAFETY(A) 1
52 FMKL4013-001 EJECT SAFETY(B) 1
53 FMKW4007-001 SPRING (A) 1 EJECT SAFETY(A)
54 FMKW4008-001 SPRING (B) 1 EJECT SAFETY(B)
55 GV20055-001A HOLDER BRACKET 1
56 QYSBSG3010Z T.SCREW 2 F.P.TO H.BKT
57 QYSBSG3010Z T.SCREW 2 F.P.TO CHS.BASE
58 QYSBSG3010Z T.SCREW 3 MECHA & H.BKT
59 QYSBSF3012Z SCREW 4 MECHA & F.PANEL
60 QYSBSG3010Z T.SCREW 2 TRANS SHD/C.BASE
61 --------------- SVC3 MECHA UNIT 1
62 E309662-001SM DISC STOPPER 1
63 QYSBSF3008Z SCREW 1 FOR DISC STOPPER
64 GV10025-001A CHASSIS BASE 1
65 E75896-006 FELT SPACER 2 CHAS.BASE FOOT
66 GV30083-001A HEAT SINK 1
67 QYSBSG3014Z T.SCREW 2 FOR LEAF SPRING
68 QYSBSG3020E TAP SCREW 2 FOR IC BRACKET
69 GV40029-001A LEAF SPRING 1
70 GV30080-001A IC BRACKET 1
71 QYSDSTL4008Z SPECIAL SCREW 4
72 GV30079-001A TRANS.SHIELD 1
73 QYSBSGG3008E T.SCREW 1 M.BOARD & C.BASE
74 QMPK090-205-JN POWER CORD US1
QMPR110-200-JN POWER CORD UX1
75 QZW0033-001 STRAIN RELIEF 1
78 QQT0276-004 TRANSFORMER
A
1 T001
79 QMF51E2-3R15-J1 FUSE
A
1 F001
80 QMF51E2-3R15-J1 FUSE
A
1 F101
81 QMF51E2-3R15-J1 FUSE
A
1 F102
82 QUQ412-1028CJ FFC WIRE 1 FC315
83 QUQ412-1112DJ FFC WIRE 1 FC869
84 QUQ610-0915BJ FFC WIRE 1 FC879
85 QUQ110-1908BJ FFC WIRE 1 FC868
86 QUQ412-0917CJ FFC WIRE 1 FC865
87 QUQ412-1112DJ FFC WIRE 1 FC880
88 QUQ412-1112DJ FFC WIRE 1 FC906
89 GV10026-030A REAR PANEL 1 MX-J680V
GV10026-028A REAR PANEL 1 MX-J570V
90 E207356-002SM REAR COVER 1
91 QYSBSF3010Z SCREW 2 SVC3/STAY BKT
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
92
QYSBSGY3008M SPECIAL SCREW
2
ANTENA/R.PANEL
93
QYSBSGY3008M SPECIAL SCREW
1
AUX TERM/R.PANEL
94
QYSBSGY3008M SPECIAL SCREW
2
SPK TERM/R.PANEL
95
QYSBSGY3008M SPECIAL SCREW
4
H.SINK/ R.PANEL
96
QYSBSGY3008M SPECIAL SCREW
2
R.COVER/R PANEL
97
QYSBSGY3008M SPECIAL SCREW
1
GROUND /R.PANEL
98
QYSBSGY3008M SPECIAL SCREW
2
SVC3/REAR PANEL
99
QYSBSGY3008M SPECIAL SCREW
1
R.PANEL/C.BASE
100
QYSBSGY3008M SPECIAL SCREW
1
OPTICAL OUT/R.PANEL
101
GV10024-003A/S/ METAL COVER
1
MX-J680V
GV10024-001A/S/ METAL COVER
1
MX-J570V
102
QYSDSG3006N T.SCREW
2
M.COVER+C.BASE
103
QYSBSGY3008M SPECIAL SCREW
6
M.COVER+R.PANEL
104
GV30074-001A CD FITTING
1
DISC 1
105
GV30075-001A CD FITTING
1
DISC 2
106
GV30076-004A CD FITTING
1
DISC 3
107
GV30084-002A KNOB(BASS&VOL.)
2
MX-J680V
GV30084-001A KNOB(BASS&VOL.)
2
MX-J570V
108
GV10028-009A WINDOW SCREEN
1
MX-J570V
GV10028-010A WINDOW SCREEN
1
MX-J680V
109
QYSDSF2608Z SCREW
2
110
FMYH4004-001 PLASTIC RIVET
2
TUNER BRD.HOLDER
113
GV30104-001A PROTECT SHHET
1
114
GV40082-001A MIC BRACKET
1
115
QYSDSF2608Z SCREW
2
MIC BKT.+F.PANEL
116
QYSBST3006Z T.SCREW
1
MIC BRD./MIC.BKT
117
VKZ4001-110 WIRE CLAMP
1
118
QMF51E2-1R6-J1 FUSE
A
1
F003
119
QYSBSF3012M SCREW
2
VOL.SEL/R.PANEL
120
GV40083-001A MIC VOL.KNOB
1
121
GV40123-001A SPACER
1
STICK TO BRIDGE
122
GV30032-001A FL HOLDER
1
123
E3400-439 FELT SPACER
2
124
LV30830-002A BRACKET
1
125
QYSBSF3008Z SCREW
1
BRACKET/SVC3
126
E310243-002 PLASTIC RIVET
2
V.BRD./BRACKET
127
QYSBSF3008Z SCREW
1
REG.BRD./SVC3
128
QUQB10-1909BJ FFC WIRE
1
FC100
129
QUQ410-0508CJ FFC WIRE
1
FC101
130
QUQ410-2306CJ CARD WIRE US
1
FC151(MX-J680V)
FSQ110-2306AJC CARD WIRE UX
1
FC151(MX-J680V)
QUQ410-2306CJ CARD WIRE US,UX
1
FC151(MX-J570V)
131
QYSBSGY3008M SPECIAL SCREW
1
VIDEO OUT/R.PANEL
