MX-J570V/MX-J680V

3-13

Item

Parts number Parts name Area

Electrical parts list (Power supplly&input/output board)

Remarks

Block No. 01

C 201 QFV72AJ-104Z M CAPACITOR .10MF 5% 100V

C 202 QFV72AJ-104Z M CAPACITOR .10MF 5% 100V

C 203 QFV72AJ-104Z M CAPACITOR .10MF 5% 100V

C 204 QEZ0510-478 E CAPACITOR 4700MF

C 205 QEZ0510-478 E CAPACITOR 4700MF

C 211 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 212 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 213 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 214 EETB1VM-228JC E CAPACITOR

C 215 EETB1VM-228JC E CAPACITOR

C 216 QETN1VM-107Z E CAPACITOR 100MF 20% 35V

C 217 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 218 EETC1HM-226ZJC E CAPACITOR

C 219 FQDYB1CM-103Y C CAPACITOR

C 220 EETC1HM-226ZJC E CAPACITOR

C 221 EETC1HM-475ZJC E CAPACITOR

C 222 EETC1HM-475ZJC E CAPACITOR

C 223 EETC1HM-226ZJC E CAPACITOR

C 233 QFVJ1HJ-224Z CAPACITOR .22MF 5% 50V

C 253 EETB1EM-338JC E CAPACITOR

C 403 EETC1AM-477ZJC E CAPACITOR

C 404 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 411 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 412 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 415 FQDGB1HK-102Y C CAPACITOR

C 426 FQDVB1EZ-223Y C CAPACITOR

C 427 EETC1EM-106ZJC E CAPACITOR

C 433 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 434 QETN0JM-108Z E CAPACITOR 1000MF 20% 6.3V

C 436 EETC1AM-107ZJC E CAPACITOR

C 437 EETC1EM-106ZJC E CAPACITOR

C 438 FQDYB1CM-103Y C CAPACITOR

C 439 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 440 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 441 QTE1V06-106Z E CAPACITOR

C 442 QTE1V06-106Z E CAPACITOR

C 443 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 444 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 445 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 446 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 447 QTE1V06-106Z E CAPACITOR

C 448 QTE1V06-106Z E CAPACITOR

C 449 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 450 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 453 QFVJ1HJ-154Z TF CAPACITOR .15MF 5% 50V

C 454 QFVJ1HJ-154Z TF CAPACITOR .15MF 5% 50V

C 455 QFVJ1HJ-274Z CAPACITOR .27MF 5% 50V

C 456 QFVJ1HJ-274Z CAPACITOR .27MF 5% 50V

C 457 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 458 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 459 QFLM1HJ-183Z M CAPACITOR .018MF 5% 50V

C 460 QFLM1HJ-183Z M CAPACITOR .018MF 5% 50V

C 461 QFLM1HJ-562Z M CAPACITOR 5600PF 5% 50V

C 462 QFLM1HJ-562Z M CAPACITOR 5600PF 5% 50V

C 466 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 467 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 468 EETC1EM-226ZJC E CAPACITOR

C 469 QFLM1HJ-683Z M CAPACITOR .068MF 5% 50V

C 470 QFVJ1HJ-274Z CAPACITOR .27MF 5% 50V

C 471 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 472 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 473 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 474 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 475 EETC1HM-105ZJC E CAPACITOR

C 476 QFLM1HJ-682Z M CAPACITOR 6800PF 5% 50V

C 488 EETC1HM-226ZJC E CAPACITOR

C 526 EETC1AM-107ZJC E CAPACITOR

C 527 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 528 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 529 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 530 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 531 QTE1C06-476Z E CAPACITOR

C 532 QTE1C06-476Z E CAPACITOR

C 535 EETC1AM-107ZJC E CAPACITOR

C 579 QETN1HM-474Z E CAPACITOR .47MF 20% 50V

C 580 QFVJ1HJ-184Z TF CAPACITOR .18MF 5% 50V

C 581 EETC1HM-105ZJC E CAPACITOR

C 703 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V

C 704 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V

C 705 FQCSB1HJ-220Y C.CAPACITOR

C 706 FQCSB1HJ-220Y C.CAPACITOR

C 707 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 708 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 709 FQCSB1HJ-100Y C CAPACITOR

C 710 FQCSB1HJ-100Y C CAPACITOR

C 711 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 712 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 713 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V

C 714 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V

C 715 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V

C 716 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V

C 721 QTE1V06-106Z E CAPACITOR

C 722 QTE1V06-106Z E CAPACITOR

C 723 EETC1HM-226ZJC E CAPACITOR

C 726 EETC1EM-106ZJC E CAPACITOR

C 729 EETC1CM-476ZJC E CAPACITOR

C 730 FQCF31HZ-223Z D.CAPACITOR

C 731 FQCF31HZ-223Z D.CAPACITOR

C 732 FQDXB1CM-222Y C CAPACITOR

C 733 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 734 FQDXB1CM-222Y C CAPACITOR

C 735 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C 739 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V

C 742 EETC1HM-224ZJC E CAPACITOR

C 743 QFLM1HJ-823Z M CAPACITOR .082MF 5% 50V

CN315 QGF1205F1-10 CONNECTOR

CN612 QGB2510J1-04 CONNECTOR

CN701 QGB2510K2-07 CONNECTOR

CN702 QGB2510K2-10 CONNECTOR

CN711 QGB2510J1-07 CONNECTOR

CN712 QGB2510J1-10 CONNECTOR

CN870 QGB1214J1-20S CONNECTOR

CN871 QGB1214J1-20S CONNECTOR

CN912 QGD2503F1-05 SOCKET

C1022 FQDGB1HK-102Y C CAPACITOR

C1023 FQDGB1HK-102Y C CAPACITOR

C1034 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V

C1035 EETC1AM-107ZJC E CAPACITOR

C1036 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

C1037 FQDYB1CM-103Y C CAPACITOR

C1038 FQDXB1CM-472Y C CAPACITOR

C1039 FQDYB1CM-103Y C CAPACITOR

C1040 FQDXB1CM-332Y C CAPACITOR

C1041 FQDYB1CM-103Y C CAPACITOR

C1042 EETC1EM-226ZJC E CAPACITOR

C1043 QFVJ1HJ-474Z CAPACITOR .47MF 5% 50V

Item

Parts number Parts name Area

Remarks

Electrical parts list
