MX-J570V/MX-J680V
3-14
Item
Parts number Parts name Area
Remarks
A
C1044 FQDYB1CM-103Y C CAPACITOR
C1045 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1061 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C1062 EETC1AM-107ZJC E CAPACITOR
C1063 EETC1HM-475ZJC E CAPACITOR
C1064 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1065 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1066 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1067 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1068 QETN1HM-224Z E CAPACITOR .22MF 20% 50V
C1069 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
D 201 1N5402M-20 DIODE
A
D 202 1N5402M-20 DIODE
A
D 203 1N5402M-20 DIODE
A
D 204 1N5402M-20 DIODE
A
D 211 1N5402M-20 DIODE
A
D 212 1N5402M-20 DIODE
A
D 213 1N5402M-20 DIODE
A
D 214 1N5402M-20 DIODE
A
D 217 1N4003S-T5 SI DIODE
A
D 218 1N4003S-T5 SI DIODE
A
D 219 MTZJ33C-T2 Z DIODE
D 220 MTZJ9.1B-T2 ZENER DIODE
D 221 MTZJ5.1B-T2 ZENER DIODE
D 223 1SS133-T2 SI DIODE
D 227 1N4003S-T5 SI DIODE
A
D 233 2A02-M DIODE
A
S4 CCT
D 234 2A02-M DIODE
A
S4 CCT
D 411 1SS133-T2 SI DIODE
D 412 1SS133-T2 SI DIODE
D 426 MTZJ5.1B-T2 ZENER DIODE
D 431 1SS133-T2 SI DIODE
D 432 1SS133-T2 SI DIODE
D 433 1SS133-T2 SI DIODE
D 434 MTZJ5.1B-T2 ZENER DIODE
D 434 MTZJ5.1B-T2 ZENER DIODE
D 573 1SS133-T2 SI DIODE
D 703 MTZJ15C-T2 Z DIODE
D 704 MTZJ15C-T2 Z DIODE
D 719 1SS133-T2 SI DIODE
D 720 1SS133-T2 SI DIODE
D 723 MTZJ33C-T2 Z DIODE
D 724 MTZJ33C-T2 Z DIODE I M
D 725 1SS133-T2 SI DIODE
D 728 1SS133-T2 SI DIODE
D 742 MTZJ2.4B-T2 Z.DIODE
D1021 MTZJ5.1B-T2 ZENER DIODE
D1022 MTZJ2.4B-T2 ZENER DIODE
D1061 1SS133-T2 SI DIODE
FT111 QNG0020-001Z FUSE CLIP
FT112 QNG0020-001Z FUSE CLIP
FT131 QNG0020-001Z FUSE CLIP
FT132 QNG0020-001Z FUSE CLIP
FT511 QNG0020-001Z FUSE CLIP
FT512 QNG0020-001Z FUSE CLIP
FT521 QNG0020-001Z FUSE CLIP
FT522 QNG0020-001Z FUSE CLIP
FW431 QUM156-14Z4Z4 FLAT WIRE
FW703 QUM156-14DGZ4 FLAT WIRE
FW704 QUM154-15DGZ4 FLAT WIRE
FW705 QUM156-11Z4Z4 FLAT WIRE
FW902 QUM155-32DGZ4 FLAT WIRE
IC436 TDA7439 IC
IC466 BA3837 IC(VOCALFADER)
IC526 BA15218 IC
IC701 STK412-000 IC(HYBRID)
A
IC901 NJM4580L IC
IC902 BU9253AS IC
J 81 QNB0098-001 SPK TERMINAL
J 411 QNN0117-001 PIN JACK
J 426 GP1FA550TZ OPT TRANSMITTER
J1021 QNS0080-001 6.3 JACK
J1022 QNS0080-001 6.3 JACK
L 701 QQLZ005-R45 INDUCTOR
L 702 QQLZ005-R45 INDUCTOR
Q
201 KTA1023/OY/-T TRANSISTOR
Q
203 KRC107M-T D.TRANSISTOR
Q
204 KTC3199/GL/-T TRANSISTOR
Q
240 KTC3199/GL/-T TRANSISTOR
Q
401 2SC3576-JVC-T TRANSISTOR
Q
402 2SC3576-JVC-T TRANSISTOR
Q
483 KRA101M-T TRANSISTOR
Q
561 2SC3576-JVC-T TRANSISTOR
Q
562 2SC3576-JVC-T TRANSISTOR
Q
571 2SC2785/FE/-T TRANSISTOR
Q
572 2SC2785/FE/-T TRANSISTOR
Q
573 2SC2785/FE/-T TRANSISTOR
Q
574 2SC2785/FE/-T TRANSISTOR
Q
575 2SC2785/FE/-T TRANSISTOR
Q
576 2SC2785/FE/-T TRANSISTOR
Q
577 KRC111M-T TRANSISTOR
Q
578 KRC111M-T TRANSISTOR
Q
579 KRC111M-T TRANSISTOR
Q
580 KRC111M-T TRANSISTOR
Q
581 KRC111M-T TRANSISTOR
Q
582 KRC111M-T TRANSISTOR
Q
701 KTA1268/GL/-T TRANSISTOR
Q
702 KTA1268/GL/-T TRANSISTOR
Q
710 2SA1038S/SE/-T TRANSISTOR
Q
711 KTC3200/GL/-T TRANSISTOR
Q
712 KTA1268/GL/-T TRANSISTOR
Q
713 2SC2389S/SE/-T TRANSISTOR
Q
726 2SC2389S/SE/-T TRANSISTOR
Q
727 KTA1268/GL/-T TRANSISTOR
Q
728 KTC3199/GL/-T TRANSISTOR
Q
733 2SC3576-JVC-T TRANSISTOR
Q
734 2SC3576-JVC-T TRANSISTOR
Q
735 2SC3576-JVC-T TRANSISTOR
Q
736 2SC3576-JVC-T TRANSISTOR
Q
737 KRA111M-T D.TRANSISTOR
Q
742 2SK301/PQ/-T TRANSISTOR(FET)
Q
1021 KRA111M-T D.TRANSISTOR
Q
1022 KRA111M-T D.TRANSISTOR
Q
1023 KRA111M-T D.TRANSISTOR
Q
1061 2SD2144S/VW/-T TRANSISTOR
R 202 QRZ9042-2R2X F RESISTOR
A
2.2 1/0W
R 203 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R 204 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 205 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 206 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 207 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 209 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 210 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 215 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 216 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 217 QRE141J-273Y C RESISTOR 27K 5% 1/4W
Electrical parts list (Power supplly&input/output board)
Block No. 01
Item
Parts number Parts name Area
Remarks
A
