JVC RM-C1305-1H - Page 2

1-2 (No. 52176)
Dimentions (W x H x D)
Mass
TV RF System
Colour System TV Mode
Video Mode
Stereo System
Receiving Frequency VHF Low
VHF High
UHF
CATV
Intermediate Frequency VIF
SIF
Colour Sub Carrier Frequency
Aerial Input Terminal
Power Input
Power Consumption
Picture Tube
High Voltage
Speaker
Audio Output
Video / Audio Input S-Video (1)
(1/2/3)
Video (1/2/3)
Audio (1/2/3)
Component (2)
Video / Audio Output Video
Audio
Headphone
Remote Control Unit
SPECIFICATION
Items
Design & specifications are subject to change without notice.
Contents
AV-21V311/B AV-21V511/B AV-21V531/B
64.9cm x 46.5cm x 47.3cm 64.9cm x 47.8cm x 47.3cm
24.5kg 23.5kg
2.4kg (Bass Blaster Unit)
B, G B, G, I, D, K, M
PAL / SECAM PAL / SECAM / NTSC3.58 / NTSC4.43
PAL / SECAM / NTSC3.58 / NTSC4.43
A2(B/G)(Bilingual), Playback A2(B/G)/NICAM (B/G, I, D/K)
46.25MHz - 140.25MHz (AS0 - S6)
147.25MHz - 423.25MHz (S7 - S36)
431.25MHz - 863.25MHz (S37 - CHINA 57)
Mid : X - Z, S1 - S10
Super : S11 - S20
Hyper : S21 - S41
38.0MHz
31.5MHz(6.5MHz) 31.5MHz(6.5MHz), NICAM: 32.15MHz(5.85MHz)
32.0MHz(6.0MHz) 32.0MHz(6.0MHz), NICAM: 31.45MHz(6.55MHz)
32.5MHz(5.5MHz), 32.5MHz(5.5MHz),
A2: 32.26MHz(5.74MHz) A2: 32.26MHz(5.74MHz), NICAM: 32.15MHz(5.85MHz)
33.5MHz(4.5MHz)
4.43MHz(PAL) 4.43MHz(PAL), 4.40MHz/4.25MHz(SECAM)
4.40MHz/4.25MHz(SECAM) 3.58MHz/4.43MHz(NTSC)
75Ω unbal anced
AC110V - AC240V, 50Hz/60Hz
126W(Max.)/81W(Avg.) 150W(Max.)/93W(Avg.)
Visible size: 50.8cm (Diagonal) / 41.6cm x 31.5cm (H x V)
29kV ± 1.5kV (at zero beam current)
6.5cm x 13cm, Oval type x 2 6.5cm x 13cm, Oval type x 2
Ø13cm ( Bass Blaster Unit)
7W + 7W 7W + 7W +13W
Mini-DIN 4pin x 1
Y : 1V(p-p), positive (negative sync provided), 75 Ω
C : 0.286V(p-p) (Burst signal), 75 Ω
1V(p-p), negative sync, 75 Ω , RCA pin jack x 3
500mV(rms) (-4dBs), high impedance, RCA pin jack x 6
RCA pin jack x 3
Y : 1V(p-p), positive (negative sync), 75 Ω
C B /C R : 0.7V(p-p), 75 Ω
1V(p-p), 75 Ω , RCA pin jack x 1
500mV(rms) (-4dBs), Low inpedance (400Hz when modulated 100%), RCA pin jack x 2
3.5mm stereo mini jack x 1
RM-C1305-1H RM-C1303-1H RM-C1307-1H
(AA/R06/UM-3 battery x 2) (AA/R06/UM-3 battery x 2) (AA/R06/UM-3 battery x 2)
