3-7
RX-E112RSL/RX-E111RSL
Item
Parts number Parts name Ar
e
a
Remarks
A
R 331 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 332 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 333 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 334 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 335 QRE141J-820Y C RESISTOR 82 5% 1/4W
R 336 QRE141J-820Y C RESISTOR 82 5% 1/4W
R 337 QRE141J-820Y C RESISTOR 82 5% 1/4W
R 338 QRE141J-820Y C RESISTOR 82 5% 1/4W
R 339 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 340 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 341 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 342 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 343 QRZ0218-R22 C RESISTOR
A
7W
R 344 QRZ0218-R22 C RESISTOR
A
7W
R 345 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 346 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 347 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 348 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 349 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 350 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 355 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 356 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 365 QRE141J-330Y C RESISTOR 33 5% 1/4W
R 366 QRE141J-330Y C RESISTOR 33 5% 1/4W
R 801 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 802 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 803 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 804 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 805 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 806 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 807 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R 808 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R 809 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 810 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 811 QRJ146J-391X UNF C RESISTOR
A
390 5% 1/4W
R 812 QRJ146J-391X UNF C RESISTOR
A
390 5% 1/4W
R 813 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 814 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 815 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 816 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 821 QRJ146J-181X UNF C RESISTOR
A
180 5% 1/4W
R 822 QRJ146J-181X UNF C RESISTOR
A
180 5% 1/4W
R 823 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 824 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 825 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 826 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 827 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 828 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 831 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 832 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 833 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 834 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 835 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 836 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 837 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 838 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 839 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 840 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 841 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 842 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 843 QRZ0218-R22 RESISTOR
A
7W
R 844 QRZ0218-R22 RESISTOR
A
7W
R 845 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
Electrical parts list (Power amp board)
Block No. 01
Item
Parts number Parts name Ar
e
a
Remarks
A
R 850 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 851 QRJ125J-330 UNF OMF RESISTO
A
33 5% 1/2W
R 852 QRJ125J-330 UNF OMF RESISTO
A
33 5% 1/2W
R 853 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 854 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 855 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 856 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 857 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 858 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 859 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 860 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 861 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 862 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 863 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R 864 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R 865 QRE141J-820Y C RESISTOR 82 5% 1/4W
R 866 QRE141J-820Y C RESISTOR 82 5% 1/4W
R 867 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 868 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 901 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 903 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 905 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 907 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R 909 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 911 QRJ146J-301X UNF C RESISTOR
A
300 5% 1/4W
R 913 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 915 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 921 QRJ146J-181X UNF C RESISTOR
A
180 5% 1/4W
R 923 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 925 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 927 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 931 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 933 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 935 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 937 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 939 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 941 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 943 QRZ0218-R22 C RESISTOR
A
7W
R 945 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 947 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 949 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 951 QRJ125J-330 UNF OMF RESISTO
A
33 5% 1/2W
R 953 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 955 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 957 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 959 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 961 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 963 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R 965 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 967 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
RY201 QSK0142-001 RELAY
A
RY202 QSK0109-001 RELAY
A
T 202 QQT0281-002 POWER TRANSF
A
TA201 QNZ0079-001Z TAB IM
TA202 QNZ0079-001Z TAB IM
TA301 QNZ0079-001Z TAB IM
TA302 QNZ0079-001Z TAB IM
TA303 QNZ0079-001Z TAB IM
TA304 QNZ0079-001Z TAB IM
TA305 QNZ0079-001Z TAB IM
TA306 QNZ0079-001Z TAB IM
TA307 QNZ0079-001Z TAB IM
TA308 QNZ0079-001Z TAB IM
TW202 QUB220-08HPDM SIN TWIST WIRE
VR301 QVP0008-102Z SEMI V RESISTOR
VR302 QVP0008-102Z SEMI V RESISTOR
R 846 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 847 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 848 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 849 QRE141J-123Y C RESISTOR 12K 5% 1/4W
