a
Remarks
A
AT101 QNB0014-001 ANT TERMINAL
BK 1 LV31618-001A SHIELD BKT
C 101 NCB21HK-103X C CAPACITOR
C 103 NCB21HK-223X C CAPACITOR
C 105 NCB21HK-223X C CAPACITOR
C 107 QEKC1CM-226Z E CAPACITOR 22MF 20% 16V
C 111 NCB21HK-473X C CAPACITOR
C 112 NDC21HJ-120X C CAPACITOR
C 113 QCSB1HJ-120Y C CAPACITOR 12PF 5% 50V
C 121 NDC21HJ-120X C CAPACITOR
C 122 NDC21HJ-120X C CAPACITOR
C 123 NCB21HK-473X C CAPACITOR
C 126 NCS21HJ-101X C CAPACITOR
C 128 QENC1HM-474Z NP E CAPACITOR .47MF 20% 50V
C 129 NCB21HK-102X C CAPACITOR
C 130 QEKC1AM-107Z E CAPACITOR 100MF 20% 10V
C 133 QEKC1CM-226Z E CAPACITOR 22MF 20% 16V
C 134 NCB21HK-222X C CAPACITOR
C 135 NCB21HK-223X C CAPACITOR
C 136 QEKC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 137 NCS21HJ-680X C CAPACITOR
C 139 NCB21HK-473X C CAPACITOR
C 140 NCB21HK-473X C CAPACITOR
C 141 NCB21HK-473X C CAPACITOR
C 143 NCB21HK-223X C CAPACITOR
C 144 NCB21HK-473X C CAPACITOR
C 146 QEKC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 147 QEKC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 148 QEKC1HM-224Z E CAPACITOR .22MF 20% 50V
C 149 QEKC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 150 QEKC1CM-226Z E CAPACITOR 22MF 20% 16V
C 156 QDGB1HK-102Y C CAPACITOR
C 157 NCB21HK-473X C CAPACITOR
C 158 QEKC1CM-226Z E CAPACITOR 22MF 20% 16V
C 161 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C 162 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C 163 NCB21HK-223X C CAPACITOR
C 164 NCB21HK-473X C CAPACITOR
C 168 QEKC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 184 QEKC1CM-107Z E CAPACITOR 100MF 20% 16V
C 185 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C 186 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C 191 NCS21HJ-820X C CAPACITOR
C 192 NCS21HJ-470X C CAPACITOR
C 193 NCB21HK-561X C CAPACITOR
C 194 NCB21HK-104X C CAPACITOR
C 195 NCB21HK-331X C.CAPA. C.M
C 196 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 197 NCB21HK-473X C CAPACITOR
C 199 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
CF101 QAX0704-001Z C.FILTER
CF102 QAX0704-001Z C.FILTER
CF103 QAX0519-001Z C FILTER
CN111 QGB2501K2-12 CONNECTOR
CN112 QGB2501K1-04 CONNECTOR
D 121 1SS133-T2 SI DIODE IM
D 123 1SS133-T2 SI DIODE IM
D 129 1SS133-T2 SI DIODE IM
D 131 1SS133-T2 SI DIODE IM
IC102 LA1838 IC
IC121 LC72136N IC
IC191 SAA6588 IC(RDS)
L 112 QQL231K-2R7Y INDUCTOR
121 KRA103M-T TRANSISTOR *
R 103 NRSA02J-101X MG RESISTOR
R 104 NRSA02J-272X MG RESISTOR
R 105 NRSA02J-391X MG RESISTOR
R 106 NRSA02J-102X MG RESISTOR
R 107 NRSA02J-561X MG RESISTOR
R 108 NRSA02J-332X MG RESISTOR
R 109 NRSA02J-221X MG RESISTOR
R 111 NRSA02J-182X MG RESISTOR
R 112 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R 114 NRSA02J-272X MG RESISTOR
R 115 NRSA02J-104X MG RESISTOR
R 119 NRSA02J-103X MG RESISTOR
R 122 NRSA02J-472X MG RESISTOR
R 124 NRSA02J-222X MG RESISTOR
R 126 NRSA02J-562X MG RESISTOR
R 127 NRSA02J-822X MG RESISTOR
R 128 NRSA02J-472X MG RESISTOR
R 129 NRSA02J-222X MG RESISTOR
R 130 QRZ9005-680X F RESISTOR 68 1/4W
R 132 NRSA02J-393X MG RESISTOR
R 133 NRSA02J-392X MG RESISTOR
R 134 NRSA02J-102X MG RESISTOR
R 140 NRSA02J-563X MG RESISTOR
R 141 NRSA02J-102X MG RESISTOR
R 142 NRSA02J-470X MG RESISTOR
R 143 NRSA02J-562X MG RESISTOR
R 144 NRSA02J-332X MG RESISTOR
R 145 NRSA02J-103X MG RESISTOR
R 146 NRSA02J-472X MG RESISTOR
R 147 NRSA02J-332X MG RESISTOR
R 150 NRSA02J-331X MG RESISTOR
R 157 NRSA02J-272X MG RESISTOR
R 158 NRSA02J-272X MG RESISTOR
R 161 NRSA02J-102X MG RESISTOR
R 162 NRSA02J-102X MG RESISTOR
R 182 NRSA02J-103X MG RESISTOR
R 183 NRSA02J-103X MG RESISTOR
R 184 NRSA02J-103X MG RESISTOR
R 191 NRSA02J-102X MG RESISTOR
R 192 NRSA02J-474X MG RESISTOR
R 193 NRSA02J-103X MG RESISTOR
R 194 NRSA02J-103X MG RESISTOR
RF101 QAU0119-001 FRONT END FOR FTZ
T 111 QQR0871-001 COIL BLOCK
T 142 QQR0973-001 IFT
X 121 QAX0402-001 CRYSTAL
X 191 QAX0263-001Z CRYSTAL
Electrical parts list (Tuner board)
Block No. 05
Item
Parts number Parts name Ar
