English
5 Connecting the Center speaker
• To connect the center speaker, use the same type of
speaker cord (5 m; tagged with “CENTER”) as used for
connecting the front speakers.
Insert the speaker cord into the speaker
terminal.
Black
Press and hold
the clamp.
Insert the exposed
core of the speaker
cord fully into the
terminal.
Release your finger.
Black
White
Make sure to match the polarity (ª and ·); otherwise,
the sound will lose the surround effect.
After connecting, check that the exposed cores are fully
inserted into the terminal.
White
– 4 –
