3-11
VS-DT2000
Item
Parts number Parts name Ar
ea
Remarks
A
C1942 QTE1E06-476Z E CAPACITOR
C3101 QTE1V06-106Z E CAPACITOR
C3102 QDGB1HK-681Y C CAPACITOR
C3103 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C3104 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C3108 QENC1EM-106Z NP E CAPACITOR 10MF 20% 25V
C3201 QTE1V06-106Z E CAPACITOR
C3202 QDGB1HK-681Y C CAPACITOR
C3203 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C3204 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C3208 QENC1EM-106Z NP E CAPACITOR 10MF 20% 25V
C3301 NCB31HK-223X C CAPACITOR
C3302 NCS21HJ-152X C CAPACITOR
C3304 QTE1H06-475Z E CAPACITOR
C3306 QTE1H06-476Z E CAPACITOR
C3308 QETN1CM-336Z E CAPACITOR 33MF 20% 16V
C3313 QTE1E06-476Z E CAPACITOR
C3314 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C3321 QCBB1HK-103Y C CAPACITOR .010MF 10% 50V
C3601 NCB31HK-102X C CAPACITOR
C3602 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C3801 QETN1JM-107Z E CAPACITOR 100MF 20% 63V
C3802 QETN1JM-107Z E CAPACITOR 100MF 20% 63V
C3803 NCB31HK-103X C CAPACITOR
C3804 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C3805 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C3901 NCB31HK-103X C CAPACITOR
C5101 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C5102 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C5103 QTE1H06-475Z E CAPACITOR
C5104 QTE1V06-106Z E CAPACITOR
C5105 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C5106 QFN31HJ-562Z M CAPACITOR 5600PF 5% 50V
C5107 QTE1C06-226Z E CAPACITOR
C5108 QFG32AJ-332Z PP CAPACITOR 3300PF 5% 100V
C5109 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C5110 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C5111 NCS31HJ-151X C CAPACITOR
C5112 NCB31HK-102X C CAPACITOR
C5113 NCB31HK-102X C CAPACITOR
C5201 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C5202 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C5203 QTE1H06-475Z E CAPACITOR
C5204 QTE1V06-106Z E CAPACITOR
C5205 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C5206 QFN31HJ-562Z M CAPACITOR 5600PF 5% 50V
C5207 QTE1C06-226Z E CAPACITOR
C5208 QFG32AJ-332Z PP CAPACITOR 3300PF 5% 100V
C5209 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C5210 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C5211 NCS31HJ-151X C CAPACITOR
C5212 NCB31HK-102X C CAPACITOR
C5213 NCB31HK-102X C CAPACITOR
C5301 QTE1E06-476Z E CAPACITOR
C5302 QTE1E06-476Z E CAPACITOR
C5303 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C5304 NCB31HK-102X C CAPACITOR
C5307 NCB31HK-103X C CAPACITOR
C5308 NCB31HK-103X C CAPACITOR
C5309 NCB31HK-103X C CAPACITOR
C5311 NCS31HJ-151X C CAPACITOR
C5312 NCS31HJ-151X C CAPACITOR
C5313 NCS31HJ-151X C CAPACITOR
C7001 NDC31HJ-180X C CAPACITOR
C7002 NDC31HJ-270X C CAPACITOR
C7003 NDC31HJ-330X C CAPACITOR
C7004 NDC31HJ-330X C CAPACITOR
C7005 NCB31HK-103X C CAPACITOR
C7006 NCB31CK-104X C CAPACITOR
C7007 NCB31HK-103X C CAPACITOR
C7008 QEKC1AM-107Z E CAPACITOR 100MF 20% 10V
C7009 QEZ0229-479Z E CAPACITOR 47000MF
C7010 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C7011 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C7012 NCB31HK-103X C CAPACITOR
C7013 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C7014 QFN31HJ-104Z M CAPACITOR .10MF 5% 50V
C7118 NRSA63J-103X MG RESISTOR
C7119 NRSA63J-103X MG RESISTOR
C7128 NCB31HK-103X C CAPACITOR
C7201 NCB31HK-103X C CAPACITOR
C7202 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C7203 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V
C7210 QCZ0202-155Z ML C CAPACITOR 1.5MF
C8001 QCZ0202-155Z ML C CAPACITOR 1.5MF
D 1 1SS133-T2 SI DIODE
D 2 1SS133-T2 SI DIODE
D 3 1SS133-T2 SI DIODE
D 4 1SS133-T2 SI DIODE
D1303 MTZJ5.1A-T2 ZENER DIODE
D1304 1SS133-T2 SI DIODE HP.MUTE
D1305 1SS133-T2 SI DIODE S.MUTE
D1315 1SS133-T2 SI DIODE HP
D1316 1SS133-T2 SI DIODE HP
D1801 DSK10C-T1 DIODE M.DRIV
D1802 MTZJ5.1C-T2 ZENER DIODE M.DRIV
D1803 MTZJ3.6B-T2 S.B.DIODE M.DRIV
D1901 D5SBA20-S1 SI DIODE
A
VH
D1902 D3SBA20-S1 DIODE
A
A
A
VL
D1903 1SS133-T2 SI DIODE SW10
D1904 MTZJ5.6C-T2 ZENER DIODE SW10
D1905 MTZJ10A-T2 ZENER DIODE SW10
D1906 MTZJ11A-T2 ZENER DIODE R.FIL
D1907 1SS133-T2 SI DIODE R.FIL
D1908 1SS133-T2 SI DIODE CD8
D1909 MTZJ7.5C-T2 ZENER DIODE CD8
D1910 6A10E2 SI DIODE LV
D1911 MTZJ10C-T2 Z.DIODE BL10
D1912 MTZJ13C-T2 ZENER DIODE BL10
D1913 MTZJ6.8B-T2 ZENER DIODE US5 PROTECT
D1915 1SS133-T2 SI DIODE TU5
D1916 1SS133-T2 SI DIODE TU5
D1917 1SS133-T2 SI DIODE RY
D1918 1SS133-T2 SI DIODE CD5
D1919 MTZJ5.6B-T2 ZENER DIODE CD5
D3801 1N4003S-T5 SI DIODE
D3802 1N4003S-T5 SI DIODE
D3803 1N4003S-T5 SI DIODE
D3804 MTZJ36C-T2 Z DIODE
D3805 MTZJ6.8C-T2 Z DIODE
D7001 1SS355-X DIODE
D7002 1SS133-T2 SI DIODE
D7003 1SS355-X DIODE
D7004 MTZJ5.1C-T2 ZENER DIODE
D7005 1SS133-T2 SI DIODE
D7006 1SS133-T2 SI DIODE
Electrical parts list (Main board)
Block No. 01
Item
Parts number Parts name Ar
ea
Remarks
A
A
A
