JVC XL-R5000BK Service Manual

3-4
I
HA
BC
DE
F
G
1
2
3
4
5
6
XL-R5000BK XL-R5000BK
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 LV10359-004A FRONT PANEL 1
2 VJD5429-001SS JVC MARK 1
3 LV20720-001A FL LENS 1
4 FSJD4001-002 INDICATOR 1
5 E408131-002SM REMOTE LENS 1
6 LV20721-002A P.BUTTON
(
POW
)
1
7 LV31811-001A INDICATOR
(
C
)
1
8 LV20723-001A P.BUTTON ASSY 1
9 LV41613-001A INDICATOR
(
A
)
1
10 LV20722-001A P.BUTTON
(
PLAY
)
1
11 LV31812-001A P.BUTTON
(
MENU
)
1
12 LV41614-001A INDICATOR
(
B
)
1
13 LV31814-001A JOG KNOB 1
14 LV31815-001A VOL.KNOB 1
15 LV40061-001A KNOB 2
16 LV40072-001A MIC BRACKET 1
17 VKL6752-001 SNAP PLATE 2 FOR JACK
18 QYSDSF2608Z SCREW 1 FOR MIC BKT
19 QYSDSF2608Z SCREW 9 FOR PCB A
20 QYSDSF2608Z SCREW 8 FOR PCB B
21 QYSDSF2608Z SCREW 5 FOR PCB C
22 LV10014-002A CHASSIS BASE 1
23 QZF6019-001 FOOT 4 FRONT
25 QYSBST3010Z T.SCREW 4 FOR FOOT
26 LV31244-002A SPACER 2
27 QYSBSG3008M T.SCREW 2 SPACER+CHASSIS
28 LV40062-001A CD BRACKET 4
29 QYSBST3006Z T.SCREW 4 FOR CD BKT
30 LV31813-001A CDR BRACKET
(
F
)
1
31 QYSBST3006Z T.SCREW 2 FOR CDR BKT
(
F
)
32 LV41616-001A CDR BRACKET
(
R
)
2
33 QYSBST3006Z T.SCREW 2 FOR CDR BKT
(
R
)
34 QYSBSTG3006Z T.SCREW 4 FOR MAIN PWB
35 LV20725-001A MECHA BASE 1
36 LV30225-079A SPACER 1
37 QYSBST3006Z T.SCREW 4
38 QQT0307-003 POWER TRANS
A
1 POWER TRANS
39 QYSBST3006Z T.SCREW 4 FOR TRANS
40 QYSBSG3008M T.SCREW 3 FRONT+CHASSIS
41 QYSBSTG3006Z T.SCREW 1 H.P PWB+CHASSIS
42 ----------- RC3 MECHA UNIT 1
43 QYSBST3008Z T.SCREW 4 RC3+CD BKT
44 E309662-001SM DISC STOPPER 1
45 QYSBSF3008Z SCREW 1 RC3+DISC STOPPE
46 LV30033-001A FITTING
(
L
)
1
47 LV30035-001A FITTING
(
C
)
1
48 LV30037-005A FITTING
(
U
)
1
49 CRD-RA1 CDR UNIT 1
(General assembly)
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
50 LV20726-001A FITTING
(
CDR
)
1
51 LV41617-001A CDR MARK 1
52 QYSBSG3035Z T.SCREW 2 BASE+CDR MECHA
53 QYSBST3025Z T.SCREW 2 BASE+CDR MECHA
54 LV41884-001A SPACER 1
55 LV20798-001A SHIELD CASE 1
56 QYSBST3006Z T.SCREW 4 BASE+SHIELD CAS
57 LV41894-001A SHIELD TAPE 1
58 QQR1120-001 FERRITE CORE 1 FOR CDR FFC 17P
59 LV30225-079A SPACER 1
60 LV20010-014A REAR PANEL 1
61 QMP3900-200E POWER CORD
A
1
62 QHS3771-108 CORD STOPPER 1
63 QYSBSG3008M T.SCREW 3 REAR+CHASSIS
64 QYSBSG3008M T.SCREW 2 REAR+-f-IN OUT
65 QYSBSG3008M T.SCREW 1 REAR+LINE
66 QYSBSG3008M T.SCREW 2 REAR+HEAT SINK
67 QYSBSG3008M T.SCREW 1 REAR+COMP LINK
68 QYSBSG3008M T.SCREW 1 FOR ARTH PLATE
69 QUQ412-1620CJ FFC WIRE 1 VOL.- MAIN
70 QUQ412-1514CM FFC WIRE 1 FL - MAIN
71 QUQ412-1118DJ FFC WIRE 1 KEY - MAIN
72 QUQ412-0508CJ FFC WIRE 1 H.P - MAIN
73 QUQ412-0420CF FFC WIRE 1 MIC - MAIN
74 QUQ110-1908AJ FFC WIRE 1 3CD - MAIN
75 QUQ110-1710AJ FFC WIRE 1 CDR DG - DG I/O
76 QUQ110-0912AJ FFC WIRE 1 CDR I/F - MAIN
77 QJJ015-061001 SIN CR C-C WIRE 1 CDR POWER - MAI
78 QJJ010-041404 SIN CR C-C WIRE 1 CDR - DG I/O
79 QMF51E2-R25-J1 FUSE
A
1 F901
80 QMF51E2-R25-J1 FUSE
A
1 F902
81 QMF51E2-1R25-J1 FUSE
A
1 F903
82 QMF51E2-1R6-J1 FUSE
A
1 F904
83 LV20009-311A/S/ METAL COVER 1 MAGE SHANAI
84 E406308-003 SPECIAL SCREW 4 TOP
(
SIDE
)
85 QYSBSG3008M T.SCREW 2 TOP+REAR
86 LV40203-002A HEAT SINK 1 IC921
87 QYSPSPD3008Z SCREW 4 IC921
88 E70306-001 HEAT SINK 1 IC921
89 QYSBSG3008E T.SCREW 1 IC921
90 LV30225-083A SPACER 1
91 LV31897-001A FL HOLDER 1
92 LV41884-002A SPACER 1
93 QMF51E2-R40-J1 FUSE
A
1 F905
94 VKS5011-001 VOLTAGE CONTACT 1
95 QYSBSG3008M T.SCREW 2
(General assembly)
