XL-R5000BK
3-7
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M2MM
49 VKS2250-003 TOP BRACKET 1
50 VKS5515-002 S.TRAY STOPPER 1
51 VKW5156-004 TORSION SPRING 1
52 QYSBSF2608Z T.SCREW 3
53 QYSBSF2608Z T.SCREW 2
54 --------------- CD MECHA 1
55 LV40761-003A INSULATOR 2
56 LV40866-002A INSULATOR 2
57 VKS3703-00G CLAMPER ASS'Y 1
58 QYSPST2606Z SCREW 1
59 VKW5187-001 ROD 1
60 QUQ610-1509AJ FFC WIRE 1 TRAVERSE 15
61 EWS176-008 FLAT WIRE 1 TRAVERSE 6
62 VYSA1R2-033 SPACER 1 FOR EWS176-008
63 QYSBSF2608Z T.SCREW 2 FOR CD CB
64 LE30611-001A C.B HOLDER 1 FOR CD CB
65 QYSBSF3008Z SCREW 2 FOR HOLDER
(CD changer mechansm)
