JVC XV-THA85 Service Manual

3-20
Amplifier board
Block No. [0][6][0][0]
R421 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R422 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R423 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R424 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R427 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R428 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R501 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R512 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R521 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R531 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R532 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R533 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R534 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R535 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R536 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R541 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R543 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R544 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R547 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R548 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R549 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R550 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R551 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R552 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R553 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R565 NRVA63D-622X CMF RESISTOR 6.2k Ω 1/16W D
R566 NRVA63D-132X CMF RESISTOR 1.3k Ω 1/16W D
R570 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R573 NRSA63J-162X MG RESISTOR 1.6k Ω 1/16W J
R574 NRSA63J-162X MG RESISTOR 1.6k Ω 1/16W J
R575 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R576 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R578 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R579 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R580 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R583 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R584 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R608 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R655 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R738 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R739 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R740 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R991 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
L501 NQL044K-100X COIL 10uH K
CN101 QGF0522F1-30W CONNECTOR FFC/FPC (1-30)
CN201 QGF1016F2-15W CONNECTOR FFC/FPC (1-15)
CN202 QGF1016F2-06W CONNECTOR FFC/FPC (1-6)
CN502 QGB2027L1-26X CONNECTOR B-B (1-26)
CN503 QGB2027L1-26X CONNECTOR B-B (1-26)
K101 NQR0007-002X FERRITE BEADS
K301 NQR0007-002X FERRITE BEADS
K302 NQR0007-002X FERRITE BEADS
K303 NQR0007-002X FERRITE BEADS
K304 NQR0007-002X FERRITE BEADS
K401 NQR0007-002X FERRITE BEADS
K501 NQR0007-002X FERRITE BEADS
K504 NQR0007-002X FERRITE BEADS
K505 NQR0007-002X FERRITE BEADS
K507 NQR0007-002X FERRITE BEADS
K508 NQR0007-002X FERRITE BEADS
K509 NQR0007-002X FERRITE BEADS
K510 NQR0007-002X FERRITE BEADS
K513 NQR0007-002X FERRITE BEADS
K515 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K518 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K519 NQR0007-002X FERRITE BEADS
K520 NQR0007-002X FERRITE BEADS
K556 NQR0129-002X FERRITE BEADS
K557 NQR0129-002X FERRITE BEADS
K558 NQR0129-002X FERRITE BEADS
K559 NQR0129-002X FERRITE BEADS
K560 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K561 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K562 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K563 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K564 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
 Symbol No. Part No. Part Name Description Local
K565 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K566 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K567 NQR0007-002X FERRITE BEADS
K568 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K569 NQR0007-002X FERRITE BEADS
K570 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K571 NQR0007-002X FERRITE BEADS
K572 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K573 NQR0007-002X FERRITE BEADS
K574 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K575 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K576 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K577 NQR0007-002X FERRITE BEADS
K578 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K579 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K582 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K586 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
X301 NAX0542-001X C RESONATOR 16.93MHz
X401 NAX0543-001X C RESONATOR 13.50MHz
X571 NAX0513-001X CRYSTAL 27.000MHz
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-490 IC(HYBRID)
 IC301 STK413-420 IC(HYBRID)
Q2101 KTA1267/YG/-T TRANSISTOR
Q2201 KTA1267/YG/-T TRANSISTOR
Q2301 KTA1267/YG/-T TRANSISTOR
Q3101 KTA1267/YG/-T TRANSISTOR
Q3201 KTA1267/YG/-T TRANSISTOR
Q3301 KTA1267/YG/-T TRANSISTOR
D2101 1SS133-T2 DIODE
D2201 1SS133-T2 DIODE
D2301 1SS133-T2 DIODE
D2501 MTZJ13C-T2 Z DIODE
D2502 MTZJ13C-T2 Z DIODE
D3101 1SS133-T2 DIODE
D3201 1SS133-T2 DIODE
D3301 1SS133-T2 DIODE
D3501 MTZJ13C-T2 Z DIODE
D3502 MTZJ13C-T2 Z DIODE
C2102 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C2103 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2104 QETN1AM-107Z E CAPACITOR 100uF 10V M
C2105 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C2106 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C2107 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2108 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2202 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C2203 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2204 QETN1AM-107Z E CAPACITOR 100uF 10V M
C2205 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C2206 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C2207 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2208 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2302 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C2303 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2304 QETN1AM-107Z E CAPACITOR 100uF 10V M
C2305 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C2306 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C2307 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2308 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2501 QETN1HM-107Z E CAPACITOR 100uF 50V M
C2502 QETN1EM-107Z E CAPACITOR 100uF 25V M
C2503 QETN1HM-107Z E CAPACITOR 100uF 50V M
C2504 QETN1EM-107Z E CAPACITOR 100uF 25V M
C2505 QETN1HM-107Z E CAPACITOR 100uF 50V M
C2506 QETN1HM-107Z E CAPACITOR 100uF 50V M
 Symbol No. Part No. Part Name Description Local
