15 16
Step 3: Tips1:
When locking in, the wooden handrail L needs to be properly raised, and the end of the
screw and the LA1 hole that can be seen through the wooden handrail L shall prevail, so
that the short screw can be inserted into the LA1 hole visually.
Tips2:
Only be rotated 3-5 circles, otherwise the subsequent screws will not be easily locked in
Socket head screw wrench
wooden handrail L
Short screw
LA hole
LA1 hole
Socket head screw wrench
End of short screw
LA hole
LA1 hole
Place the wooden handrail L on the back seat, insert the
short screw into the LA1 hole, use an Allen wrench to lock it
into the thread in the LA1 hole clockwise and rotate 3-5 turns
