26
Technical specifications:
VL 6 i (6”+1”) VL 8 i (8”+1”) VL 10 i (10”+1”)
Nominal load /
Programm load
200 / 400 W 250 / 500 W 350 / 700 W
Impedance
(Ohm)
8 8 8
Frequency
range
80 Hz - 19 kHz 75 Hz - 19 kHz 60 Hz - 19 kHz
Crossover
freuquency
2000 Hz 2000 Hz 2000 Hz
Dispersion
(h x v)
85° x 55° (elliptical) 85° x 55° (elliptical)
85° x 55° (elliptical)
rotatable horn
SPL nominal 93 dB (1 W / 1 m) 95 dB (1 W / 1 m) 96 dB (1 W / 1 m)
SPL max.
116 dB
Nominal load AES
119 dB
Nominal load AES
121 dB
Nominal load AES
Connectors
2x terminal screw
connectors,
2x Speakon NL 4
optional,
1x PG - plug optional
2x terminal screw
connectors,
2x Speakon NL 4
optional,
1x PG - plug optional
2x terminal screw
connectors,
2x Speakon NL 4
optional,
1x PG - plug optional
Finish
PU coating black,
white optional
PU coating black,
white optional
PU coating black,
white optional
Features 10 x M8 treads 6 x M8 treads 12 x M8 treads
Dimensions in
mm (W x H x D)
235 x 405 x 190 280 x 460 x 245 330 x 580 x 340
Weight 7 kg 9 kg 14 kg
System-
extension
(recommen-
dation)
system amplifier:
SPA 500 F, DA 428
passively channelled:
VB 15 t, VB 15 w
actively channelled:
VB 15, VB 215
system amplifier:
SMA 2000, DA 428
passively channelled:
VB 15 t, VB 15 w,
VB 18 w
actively channelled:
VB 15, VB 215, VB 18
system amplifier:
SMA 2000, DA 428
passively channelled:
VB 15 t, VB 15 w,
VB 18 w
actively channelled:
VB 15, VB 215, VB 18
Optional
accessories
speaker wall mount,
U-bracket, L-bracket,
M8 eyebolts, universal
mounting plate with TV
spigot,
100 Volt transformer
speaker wall mount,
U-bracket,
M8 eyebolts, universal
mounting plate with TV
spigot,
100 Volt transformer
speaker wall mount,
U-bracket, M8 eyebolts,
universal mounting plate
with TV spigot, cluster
mounting plate,
100 Volt transformer
