40
Technical specifications:
VL 240 (8“+1“) VL 250 (12“+1“)
Nominal load 200 W bass/mid + 50 W high 200 W bass/mid + 50 W high
Amplifier class D / class D class D / class D
Dispersion 85° x 55° elliptical 75° x 45° bi-radial
Frequency range 70 Hz – 19 KHz 60 Hz – 19 KHz
SPL nom. 95 dB (1 W / 1 m) 98 dB (1 W / 1 m)
SPL max. 120 dB nominal Load AES 123 dB nominal Load AES
Connectors
mic-in XLR, 2x line-in XLR/jack ,
RCA jack, line-out XLR
mic-in XLR, 2x line-in XLR/jack ,
RCA jack, line-out XLR
Features
side-mounted handle, swivelling
flange with variable tilt angle +/-
20°, 4 x M8 treads
side-mounted handle, swivelling
flange with variable tilt angle +/-
20°, 4 x M8 treads
Dimensions in mm
(W x H x D)
280 x 460 x 245 390 x 610 x 360
Weight 11,5 kg 18 kg
Optional accessories
Wall mount (no.2-512-019),
Mounting plate + TV-spigot
(no.2-512-007),
M8 Eyebolts (no.5-350-000),
Protective cover (no. 2-311-049)
Wall mount (no.2-512-019),
Mounting plate + TV-spigot
(no.2-512-007),
M8 Eyebolts (no.5-350-000),
Protective cover (no. 2-311-054)
