KAESER EPC Series User Manual

Fig. 4 Oil level monitoring
1 Oil level monitoring
4.2.2 Option C9
"pressure low" warning
An additional pressure switch with floating relay contacts can provide warning messages to a control
centre if pressure falls too low.
4.2.3 Option H1
Adjustable machine mountings
These mounts allow the machine to be anchored firmly to the floor.
Fig. 5 Adjustable machine mountings
1 Adjustable machine mountings
2 Threaded joint
4.2.4 Option H9
Silenced air filter
The air filter reduces the noise level of the machine. It also cleans the inlet air.
4 Design and Function
4.2 Options
No.: 9_9431_02 E
Service Manual 2-stage piston compressor
EPC
23

KAESER EPC Series Specifications

General

Type	Rotary Screw Compressor
Drive Type	Direct Drive
Cooling System	Air-cooled
Control System	Sigma Control 2.0
Weight	Varies depending on model
Noise Level	62 - 75 dB(A) (depending on model)
