KAESER EPC Series User Manual

10.15.1 Cleaning the solenoid valve
Fig. 32 Cleaning the solenoid valve
1 Solenoid valve
2 Screw
3 Coil
4 Armature
5 Spring
6 Piston
7 Enclosure
8 Connecting socket
9 Arrow showing flow direction
1. Disconnect the connecting socket from the valve.
2. Undo the screw and carefully remove the coil.
3. Clean the armature and piston.
Change the spring if damaged or worn.
4. Reassemble the valve.
5. Open the user's shut-off valve between the machine and the air system.
6. Start the machine and visually check for leaks.
10 Maintenance
10.15 Solenoid valve maintenance
60
Service Manual 2-stage piston compressor
EPC No.: 9_9431_02 E

KAESER EPC Series Specifications

General

Type	Rotary Screw Compressor
Drive Type	Direct Drive
Cooling System	Air-cooled
Control System	Sigma Control 2.0
Weight	Varies depending on model
Noise Level	62 - 75 dB(A) (depending on model)
