10.17.1 Cleaning the solenoid valve
Fig. 36 Cleaning the solenoid valve condensate drain
1 Solenoid valve
2 Screw
3 Coil
4 O-ring
5 Spring
6 Solenoid core
7 Arrow showing flow direction
8 Shut-off valve
1. Close the shut-off valve upstream of the condensate drain.
2. Undo the screw and carefully remove the coil.
3. Clean the solenoid core.
If the spring and O-ring are damaged or worn they must be replaced.
4. Reassemble the valve.
10.17.2 Changing the solenoid valve
Fig. 37 Changing the solenoid valve condensate drain
1 Shut-off valve
2 Solenoid valve
3 Screw connection
1. Close the shut-off valve upstream of the condensate drain.
10 Maintenance
10.17 Solenoid valve maintenance
64
Service Manual 2-stage piston compressor
EPC No.: 9_9431_02 E
