2.1 2.2 2.3 2.4
5.Headlight installation
3.1 Loosen the headlight screw from the front fork;Install the headlight into the
screw hole of the front fork and tighten the screw with the hexagon tool.
4. Front wheel installation
4.1 Cut the wrap rope, remove the front wheel, remove the front fork guard bar and
the front wheel cover.
4.2 Make sure the front wheels are aligned with the rear wheels before intalled .First
pull the wheel up, place the disc brake disc into the front brake clamp, then use the
No. 15 wrench to tighten the front flower drum fixing screw.
