Technical specifications ZP10 ZP12 ZP10A ZP12A
Frequency response: 72-20KHz 55-20KHz 72-20KHz 55-20KHz
Sensitivity 1w/1m: 96dB 97dB 96dB 97dB
Max SPL: 116dB 119dB 117dB 119dB
Power handling: 100w 150w 140w 200w
Horn flare dispersion: 90º x 45º 90º x 60º 90º x 45º 90º x 60º
Crossover frequency: 5000Hz 3500Hz 5000Hz 3500Hz
Impedance: 8 Ohms 8 Ohms 8 Ohms 8 Ohms
Input/Link connectors: 2 x jack 2 x speakon 2 x jack 2 x jack
Output connector: n/a n/a Jack Speakon
Mic input connector: n/a n/a XLR XLR
Pole mount: Yes Yes Yes Yes
Carry handle: Yes Yes Yes Yes
Dimensions (WxHxD mm): 370x442x319 412x547x360 370x442x319 412x547x360
Weight: 12Kg 17Kg 15.5Kg 21.5Kg
4
Due to continuous product development, specifications and appearance are subject to change.
If this product is ever no longer functional please it take to a recycling plant for environmentally friendly disposal.
© C O P Y R I G H T L A M B A p l c 2 0 0 9 . E & O E .
