Kamstrup MULTICAL 602 Technical Description

MULTICAL®602
12
KamstrupA/S∙ TechnicalDescription∙5512‐931_N1_GB_11.2016
3.2 Type number combination
MULTICAL

602 Type 602-


 

   
 
Sensor connection
Pt100 2-wire (T1-T2)
A
Pt500 4-wire (T1-T2)
B
Pt500 2-wire (T1-T2-T3)
C
Pt500 4-wire (T1-T2) w/24 V pulse inputs
D
Top module
No module
0
Energy calculation + hourly data logger
2)
2
PQ or t-limiter + hourly data logger
3
Data output + hourly data logger
5
M-Bus
7
Volume + hourly data logger
2)
9
2 pulse outputs for CE and CV + hourly data logger + scheduler
A
RTC + 2 pulse outputs for CE and CV + prog. data logger
B
2 Pulse outputs CE and CV
C
Base module
No module
00
Data + pulse inputs
10
M-Bus + pulse inputs
1)
20
Radio Router + pulse inputs
21
Prog. data logger + RTC + 4…20 mA inputs + pulse inputs
22
0/4…20 mA outputs
23
LonWorks + pulse inputs
24
Radio + pulse inputs (internal antenna) 434 or 444 MHz
25
Radio + pulse inputs (external antenna connection) 434 or 444 MHz
26
M-Bus module with alternative registers + pulse inputs
27
M-Bus module with medium data package + pulse inputs
28
M-Bus module with MC-III data package + pulse inputs
29
Wireless M-Bus, Mode C1 + pulse inputs (Ind. Key)
30
Wireless M-Bus, Mode T1 OMS 15 min. (Ind. Key)
31
Wireless M-Bus, Mode C1 Alt. reg. + pulse inputs
35
Wireless M-Bus, Mode T1 OMS 16 s (ind. Key)
36
Wireless M-Bus, Mode C1 Fixed Network (ind. Key) 38
Wireless M-Bus, Mode C1 Fixed Network (ind. Key), PDO data 39
ZigBee 2.4 GHz int.ant. + pulse inputs
60
Metasys N2 (RS485) + pulse inputs
62
SIOX module (Auto detect Baud rate)
64
BACnet MS/TP + pulse inputs
66
Modbus RTU + pulse inputs
67
GSM/GPRS (GSM6H)
80
3G GSM/GPRS module (GSM8H)
81
High Power RadioRouter + pulse inputs
84
Supply
No supply
0
Battery, D-cell
2
230 VAC high power isolated SMPS
3
24 VAC high power isolated SMPS
4
230 VAC isolated linear supply
7
24 VAC isolated linear supply
8
Pt500 sensor set
No sensor set
00
Pocket sensor set w/1.5 m cable
0A
Pocket sensor set w/3.0 m cable
0B
Pocket sensor set w/5 m cable
0C
Pocket sensor set w/10 m cable
0D
Short direct sensor set w/1.5 m cable
0F
Short direct sensor set w/3.0 m cable
0G
3 Pocket sensors in sets w/1.5 m cable
0L
3 Short direct sensors in sets w/1.5 m cable
Q3
Flo
w
sensor
/pic
k
-up unit
Supplied w/1 pcs. ULTRAFLOW

(Please specify type)
1
Supplied w/2 pcs. (identical) ULTRAFLOW

(Please specify type)
2
Prepared for 1 pcs. ULTRAFLOW

(Please specify type)
7
Prepared for 2 pcs. (identical) ULTRAFLOW

(Please specify type)
8
Prepared for meters w/electronic pulse output
K
Prepared for meters w/Reed switch output
(
Both V1 and V2)
L
Prepared for meters w/24 V active pulses
M
Meter type
Heat meter, (MID module B+D)
2
Heat/cooling meter (MID modules B+D & TS+DK268)
3
Heat meter, National approvals
4
Cooling meter (TS27.02+DK268)
5
Heat/Cooling meter
6
Volume meter, hot water
7
Volume meter, cooling water
8
Energy meter
9
Country code (language on label etc.)
XX
Require
High- Power
supply
modules

Kamstrup MULTICAL 602 Specifications

General

Flow Sensor	Ultrasonic
Display	LCD
Battery Life	Up to 16 years
Communication	M-Bus, Wireless M-Bus
Approval	MID class 2, EN 1434
Accuracy	Class 2
Pressure Rating	PN16
Application	Heating and cooling systems
Temperature Range	0°C to 180°C
