Kangaroo Sydney - Attach Handles, Magnets, and Flap Hinges

Assembly InstructionsSydney XL
22
Step 4: Tabletop Doors
Handle x1
h
Magnet x2
Catch Plate
x0
m
3.5x14 Screw x16
s1
Flap Hinge x2
h4
4x20 Fix Bolt x2
b2
h
b2
s1
s1
m
h4
s1
h4
A4
A4
V3
Attach Handle to
Panel V2 and secure
with b2 Fix Bolts.
V2
Attach Magnets and Flap
Hinges to Panel A4 with
s1 Screws as shown.
Balance Panel A4.
You may need a second person to help you.
Using s1 Screws, attach Flap Hinges to Panel V3 from
underneath as shown.
