Step 5: Drawers
6x35 Cam Bolt x10
c1
8x30 Dowel Pin x6
d1
Magnet x0
Catch Plate
x1
m
3x14 Screw x2
s2
K1
c1
s1
L2
s2
m
K3
K5
K4
c1
c1
d1
d1
d1
Attach Magnet
Catch Plate
m to Panel K1
using
s2 Screws.
Attach c1
Cam Bolts to
Panel K1.
Install L2 Lock
using s1 Screws.
Press firmly to
secure the lock ring
to the lock
mechanism.
Attach 2 c1 Cam Bolts to Panel K5.
Attach 2 c1 Cam Bolts to Panel K4.
Attach 2 d1 Dowel Pins to Panel K5.
Attach 2 d1 Dowel Pins to Panel K4.
Attach 2 d1 Dowel Pins to Panel K3.
3.5x14 Screw x2
s1
Lock x1
Key x2
L2
