Kangaroo Sydney - Step 7: Embroidery Arm;Shelf Compartment; Install Shelves in Compartment

Assembly InstructionsSydney XL
33
Step 7: Embroidery Arm/Shelf Compartment
Adhesive Foam Sheet x1
Peg x8
p1
E
E
p1
Press p1 Pegs into pre-drilled holes as
shown, at whatever height you wish.
Slide Panel E Shelves on top of p1 Pegs.
Remove the backing from the Adhesive Foam Sheet and carefully adhere
it to the bottom of the shelf compartment. NOTE: The Adhesive Foam
Sheet’s adhesive is very strong. Be precise when installing!
You may choose to use h2 Folding
Hooks.
Attach to Panel Y1 using s1 Screws.
Shelves can be used with Folding
Hooks.
Folding Hook x2
h2
3.5x14 Screw x176
s1
s1
h2
Y1
