Kanrich 915 - 915 C10 AL Color Aluminum Camera Overview; 915 C10 AL Camera Terminals and Views; 915 C10 AL Camera Specifications and Accessories

BAL (never touch)
915C10AL Color Aluminum Camera
Inside View
Mic.
White LED
CCD
SPK.
Resident 1 Call Button
Resident 2 Call Button
SW1 open door time(No.1)
←15 sec. 2 sec.→
MIC. Gain
SPK. Gain
Clockwise +
anticlockwise ─
Specifications :
Working Voltage : DC 15V from PH-915P
Current Consumption: Standby 60mA
Working 250mA
CCD: Color Sony 1/3” Board Camera
Resolution: 510(H) x 492(V)
Signal Noise Rate : More than 48db
Picture Pixels: 270,000 Pixels
Ilumination : 4 white LEDs
Communication Interface :
the modulated carrier wave signal
Installation Way : Flush Mounting Type or
Surface Mounting Type
Front Material : Aluminum Panel
Dimensions : 200(H)/120(W)/55(H) mm
Weights: 570 gs
Measurement: 0.07 cuft
Accessories: 1 Terminal connector *
screw bag *1
Terminals
In
/
O
ut
mai
n l
i
n
e +
F
G
ND m
a
in l
in
e
一
D
1(
D
oor NO
)op
en d
oo
r co
nta
c
t
D2
(
Do
o
r C
OM)
op
en d
oo
r con
tac
t
A1
(
A
u
x N
O)op
en d
oo
r con
tac
t
PT
(
for d
oo
r loc
k)
G
N
D
Door Lock
Power for
door lock
(The power of door lock must be an independent power,
door phone power can’t share power with door lock.)
A2(A
u
x N
O)
op
e
n door c
on
tac
t
V
i
deo Ou
t
G
N
D Grou
nd wire
1 2 3 4 5 6 7 8 9 10
+
-
P12
2011 Sep.
The sensor of door unlock
