Supplied Parts and Hardware
Wall Plate
A: M5 x 15mm
Bolt
C: M6 x 15mm
Bolt
B: M5 x 25mm
Bolt
E: M8 x 20mm
Bolt
G: M8 x 50mm
Bolt
L: Lag Bolt
O: Plastic Cap
M: Concrete Anchor
x4 x4 x4 x4
x4
I: Lag Bolt Washer
x6
x6
H: Washer
x4
x6
x2
P: Quick-Lock TV Bracket
x2
N: M5 x 10mm Bolt
x2
D: M6 x 25mm
Bolt
x4
F: M8 x 35mm
Bolt
x4
x4
x8
x8
Bracket Extension Parts
(assembled in separate bag)
Required Tools
Socket
Set
Phillips
Screwdriver
Hammer (for
Concrete
installs)
Stud
Finder
Level Drill
7/16”
Masonry
Bit
3/16”
Wood
Bit
Pencil
