Specifications
MODEL
A150.2 A400.4
Rated Output Power @ 4ohms 75W x 2 100W x 4
Rated Output Power @ 2 ohms 100W x 2 150W x 4
Signal to Noise Ratio > 90 dB > 90 dB
Frequency Response 20Hz~50kHz 20Hz~50kHz
Low Pass Filter 40~4000 Hz 40~4000 Hz
Crossover Slope 12dB Octave 12dB Octave
Subsonic Filter 30Hz~300Hz (HPF) 30Hz~300Hz (HPF)
Bass EQ at 45Hz 0~18dB 0~18dB
Input Gain Control 0.2V~6.0V 0.2V~6.0V
Low Level Input Impedance 20K Ohms 20K Ohms
Damping Factor >100 into 4Ohms >100 into 4Ohms
Fuse Rating 30A 40A
Dimension (W x H x L) (inches) 9-1/4”x 2-1/4”x 12-5/8” 9-1/4”x 2-1/4”x 14-5/8”
