Kaption Audio CL10D2 - Specifications; Thiele-Small Parameters

Specifications
Model CL-10D2 CL-10D4 CL-12D2 CL-12D4
Speaker Size 10" 10" 12" 12"
Sensitivity (1w/1m) 83.5 83.1 86.4 86.1
Power Handling (RMS/Power) 300/600 300/600 300/600 300/600
Impedance Dual 2ohm Dual 4ohm Dual 2ohm Dual 4ohm
Voice Coil Diameter 2" 2" 2" 2"
Mounting Depth 4.5" 4.5" 5.5" 5.5"
Magnet Weight 52oz 52oz 52oz 52oz
Thiele-Small Parameters
Model CL-10D2 CL-10D4 CL-12D2 CL-12D4
Fs (Hz) 38.8 39.7 36.7 37.5
Qts 0.628 0.715 0.633 0.765
Qms 0.45 0.45 0.45 0.45
Qes 0.74 0.9 0.8 0.96
Res (ohms) 1 1.85 1 1.85
Levc (mH) 1111
Sd (sqM) 0.0324 0.0324 0.0498 0.0498
Xmax (mm) 10 10 10 10
Dia (mm) 205 205 254 254
Vas (liter) 17.25 17.25 17.25 17.25
Mms (g) 145 138 162 155.5
Cms 116 116 116 116
Bl (T*M) 6.82 8.33 6.82 8.33
Specifications subject to change without notic
e
