6 English
STEP 1:
Attach the handle to the frame of the pres-
sure washer. Align holes, insert bolts (B), and
tighten with knobs (A).
STEP 2:
Mount the gun/hose storage (D) to the handle
and tighten with nuts (J) and washer (K).
STEP 3:
Mount the detergent hose holder (E) with
enclosed nylon rivets (C) to pressure washer
STEP 4:
Attach the wand (I) to the spray gun (G).
Push the wand (I) into the trigger gun (G) and
then thread the connection.
Description Purpose Illustration Qty
H
Wand Wand Assembly 1
I
Nut Gun/Hose Storage
Assembly
2
J
Washer Gun/Hose Storage
Assembly
2
Hardware (included)
Assembling

Kärcher G 2800 OC Specifications

General

Maximum flow rate	522.39 l/h
Working pressure (max)	193 bar
Maximum input water temperature	60 °C
Form factor	Compact
Hose length	7.62 m
Power source	Gasoline
Product color	Black, Yellow
Pressure range	High-pressure
Surface cleaner	-

Weight and Dimensions

Depth	558.8 mm
Width	584.2 mm
Height	889 mm
Weight	30118 g
