Operating Instructions HD 645 / HD 650 (SX) / HD 658 / HD 690 (SX) English
27
Technical specifications
HD 690 SX 1.151-
-201 -202 -203
HD 690 1.151-
-101 -102 -103 -107 -108 -109
Mains connection EU I EU II AUS/GB BR KAP KAP
Voltage V 400 230 420 230 380 220
Type of current Hz 3~50 3~50 3~50 3~60 3~50 3~60
Connected load kW 4.7 4.7 4.7 4.7 4.7 4.7
Supply fuse (delayed-action) A 16 16 16 16 16 16
Extension cable 10 m mm² 1.5 1.5 1.5 1.5 1.5 1.5
Extension cable 30 m mm² 1.5 2.5 1.5 2.5 1.5 2.5
Water connection
Supply temperature (max.) °C 60 60 60 60 60 60
Supply volume (min.) l/h 800 800 800 800 800 800
Supply hose – length m 7.5 7.5 7.5 7.5 7.5 7.5
Supply hose – minimum diameter inches 1/2 1/2 1/2 1/2 1/2 1/2
Suction height from an open container
20 °C
m 0.5 0.5 0.5 0.5 0.5 0.5
Supply pressure (max.) bar 10 10 10 10 10 10
Performance data
Operating pressure bar 20–175 20–175 20–175 20–175 20–175 20–175
Flow rate l/h 240–700 240–700 240–700 240–700 240–700 240–700
Detergent intake l/h 0–48 0–48 0–48 0–48 0–48 0–48
Recoil force of the handgun N 34 34 34 34 34 34
Noise emission
Sound level (EN 60704-1) dB(A) 78 78 78 78 78 78
Guaranteed sound power level
(2000/14/EC)
dB(A)959595959595
Dimensions
Length mm 400 400 400 400 400 400
Width mm 340 340 340 340 340 340
Height mm 900 900 900 900 900 900
Weight without accessories kg 26.5 26.5 26.5 26.5 26.5 26.5
Weight with accessories, HD 690 SX kg 35.5 35.5 35.5
Reservoir capacity, detergent l 7 7 7 7 7 7
Oil quantity, pump l 0,4 0,4 0,4 0,4 0,4 0,4
Oil type, pump motor oil SAE90
