English 13
Warranty
The warranty conditions issued by our sales company
responsible apply in all countries. We shall remedy pos-
sible malfunctions on your device within the warranty
period free of cost, provided that a material or manufac-
turing defect is the cause. In a warranty case, please
contact your dealer (with the purchase receipt) or the
next authorised customer service site.
(See overleaf for the address)
Technical data
Subject to technical modifications.
EU Declaration of Conformity
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements in the EU Directives, both in its basic design
and construction as well as in the version placed in cir-
culation by us. This declaration is invalidated by any
changes made to the machine that are not approved by
us.
Product: High-pressure cleaner
Type: K 5 Classic
Currently applicable EU Directives
2000/14/EC
2006/42/EC (+2009/127/EC)
2011/65/EU
2014/30/EU
Harmonised standards used
EN 60335-1
EN 60335-2-79
EN 55014-1: 2017 + A11: 2020
EN 55014-2: 1997 + A1: 2001 + A2: 2008
EN 61000-3-2: 2014
EN 61000-3-11: 2000
EN IEC 63000: 2018
Conformity evaluation procedure used
2000/14/EC: Annex V
Sound power level dB(A)
Measured: 89
Guaranteed: 92
The signatories act on behalf of and with the authority of
the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Ph.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2023/10/01
Electrical connection
Voltage V 220-240
Phase ~ 1
Frequency Hz 50
Maximum permissible mains grid
impedance
Ω 0,34 +
j0,21
Current consumption A 8
Degree of protection IPX5
Protection class II
Power protection (slow-blowing) A 10
Water connection
Feed pressure (max.) MPa 1,2
Input temperature (max.) °C 40
Input amount (min.) l/min 10
Suction height (max.) m 0,5
Device performance data
Operating pressure MPa 12,0
Max. permissible pressure MPa 14,5
Water flow rate l/min 6,7
Maximum flow rate l/min 8,3
Detergent flow rate l/min 0,3
High-pressure gun recoil force N 17
Dimensions and weights
Typical operating weight kg 7,0
Length mm 281
Width mm 274
Height mm 461
Determined values in acc. with EN 60335-2-79
Hand-arm vibration value m/s
2
2,3
Uncertainty K m/s
2
0,7
Sound pressure level L
pA
dB(A) 77
Uncertainty K
pA
dB(A) 3
Sound power level L
WA
+
uncertainty K
WA
dB(A) 92
