7
Choosing A Input
3) Plug the power supply into the opening DC 12V (8) on the back of the IR
Transmitter.
We have included all the parts to install in 3 different ways. TOS Digital Optical
(best way), RCA analog (next best) and 3.5mm audio.
If this port is on your device proceed to “OPTICAL INSTALL” in this manual, if none
of your devices have the DIGITAL AUDIO OUT (OPTICAL) port, look for the RCA
AUDIO OUT, this can be located on the TV, Satellite or cable box. If you find the
RCA “AUDIO OUT” install with the “RCA INSTALL”,
Ports on the front of the your system are normally AUDIO IN and will not send audio
to the KARE Speaker.
At the back of your TV, you will find the DIGITAL AUDIO OUT (OPTICAL) port. If
audio out ports are not available on your Television, use the audio ports on your
cable or satellite box.
the IR Transmitter must remain plugged in to transmit the signal.
DIGITAL
AUDIO
OUT
(OPTICAL)
To Next Page
