Karella Premium Silver - Dartboard Component Overview; Component Identification

Electronic Dartboard Karella Premium Silver 5
Art.Nr. 8075.01
1
Catch Ring
14
Power button
25
Double Out Indicators
2
Singles Ring
15
Double/Miss button
26
Master Out Indicators
3
Doubles Ring
16
Cybermatch button
27
Temporary Score
4
Triples Ring
17
Game button
<display
5
Speaker
18
Quick-Pick button
28
Cricket Scoring
6
Start/Hold button
19
Built-in Dart Holders
Display
7
Reset button
20
Storage Drawer/
29
Cricket Segment
8
Player/Page button
Game Menü
Display
9
Bounce Out button
21
Score Display
30
External Speaker
10
Sound button
Indicators
Jack (on side)
11
Select button
22
Player Indicators
31
Power Switch and
12
Dart Out/Score button
23
Hold Indicators
Adapter Jack (on side)
13
Game Guard button
24
Double In Indicators
