1. I typed http://192.168.10.1 in my Internet Browser's Address Bar, but an error message says

“The page cannot be displayed.” How can I get into the W150NR's web configuration page?

2. Make sure the LAN and WLAN lights are lit.

3. Make sure your TCP/IP settings are set to Obtain an IP address automatically (see the steps

below).

4. Press on the factory reset button for 15 seconds.

Check your hardware settings again by following the instructions in Section 2.

Troubleshooting

Windows 7

1. Go into the Control Panel, click Network and

Sharing Center, click Change Adapter

Settings and then right-click the Local Area

Connection icon and then click Properties.

2. Click Internet Protocol Version 4 (TCP/IPv4)

and then click Properties. Then click on Obtain

an IP address automatically.

Windows Vista

1. Go into the Control Panel, click Network and

Internet, click Network and Sharing Center,

click Manage Network Connections and then

right-click the Local Area Connection icon and

then click Properties.

2. Click Internet Protocol Version 4(TCP/IPv4)

and then click Properties. Then click on Obtain

an IP address automatically.

Other manuals for Keebox W150NR

Questions and Answers:

Need help?

Do you have a question about the Keebox W150NR and is the answer not in the manual?

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Input current	1 A
Rack mounting	-
Frequency range	2.4 - 2.4835 GHz
Minimum system requirements	- Internet Explorer 6.0, Firefox, Safari, Chrome
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	5
Routing protocols	RIP-1, RIP-2
Supported network protocols	PPPoE, PPTP, L2TP
Antennas quantity	1
Antenna gain level (max)	17 dBi
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Certification	- CE, FCC
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	White
Cables included	LAN (RJ-45)
