Keeson Technology MC120 User Manual

2
2.4. PowerLED&PAIRINGLED
Po
wersupplyforcontrolbox,PAIRINGLEDofcontrolboxflashesfor4times,andthenturnsoff,POWERLEDturns
on。
2.5. Power
Connecttothe29VDC;
2.6. Testforunderbedlight
Clickbuttonofunderbedlight,turnson(orturnsoff)theunderbedlight,switchthestatusoncewhenclickonce；
Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.
2.3. MULTIFUNCTIONport
ConnectwiththesameotherControlboxorOtheraccessories;
2.2. FOOT port
Connecttofootactuator,controlbyremotesingle:
Clickfoot up button，footactuatormovesout，stopwhenreleased；
Clickfoot downbutton，footactuatormovesin，stopwhenreleased；
Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.
2.1. HEADport
Connecttoheadactuator,controlbyremotesingle:
Clickhead upbuttonontheremote,headactuatormovesout,stopwhenreleased；
Clickheaddownbutton，headactuatormovesin,stopwhenreleased；
Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.
2. FunctionPicture
2.
Processoftest
MC120 Functioninstruction

Keeson Technology MC120 Specifications

General

Brand	Keeson Technology
Model	MC120
Category	Control Unit
Language	English
