Polar graphs
Directivity Index / Beamwidth
Frequency / Power response, Input impedance
Specifications
Installation
Architectural specifications:
The Ci9000ACE comprises a Uni-Q
®
array
with a
coincident mounted, twin
neodymium magnet, 19mm (
3
⁄4”) aluminium
dome
,
high-fr
equency unit
,
a 165mm
polypropylene midrange unit and two
165mm bass drivers. Performance should
meet or exceed the following criteria:
frequency response 1 metre on-axis with
swept sinewave shall be 60Hz to 27kHz,
sensitivity shall be at least 88dB for
2.83V@1m. The impedance and maximum
po
w
er shall be 150W at 8 ohms.
The
Ci9000ACE is best suited for high quality
music and home theatre applications where
hi-fi performance is required, such as:
· Multi Room systems.
· Home Theatre systems.
· Lounges, Bars, Boutiques.
· Boardrooms & Offices.
500Hz 1kHz
2kHz 4kHz
8kHz 16kHz
PL1614EN
Frequency range 60Hz - 27kHz
Sensitivity (2.83v @ 1m) 88dB
Rec
.
amplifier po
w
er
30 - 150W
Nominal Impedance 8Ω (min. 3.2Ω)
Crossover Frequency 350Hz, 3kHz
Enclosure material Steel
Terminals
screw type
Dimensions (H x
W x D)
680 x 230 x 105 mm,
26.75 x 9.05 x 4.13 in.
*
700 x 252 x 104 mm, 27.55 x 9.92 x 4.09 in.**
Net w
eight
12kg (26.4lbs)
1
3
5
2
4
67
*With inset grille **With overhanging grille
