Clearly an evolution of the award winning
3000 Series, the new KHT3005SE is the
latest version of the iconic ‘egg’ home theatre
system, updated to provide an even stronger
audio performance with improved clarity
and detail yet maintaining the beauty and
style that helped make its predecessor a
reviewer’s favourite.
The revolutionary Uni-Q driver of the
satellite and centre speaker has been
enhanced by the addition of the ingenious
‘Tangerine’ waveguide, for improved
sensitivity and sound dispersion and have
been comprehensively engineered for an
even cleaner, smoother response.
The cast aluminium enclosures are shaped to
minimise internal resonance with KEF’s
Sealed Suspension Technology - SST
TM
(patent
applied for) dramatically improves sound
quality and at higher volumes filling the room
with incredibly detailed 3D sound.
Carrying up to 60% of the sound, the centre
channel is vital in any home theatre system,
and the dedicated centre speaker is in a
class of its own providing an amazingly
clear dialogue in perfect timbre with the
satellite speakers.
Available in high gloss black and high gloss
silver finishes.
The cool minimalism of these slender cast
aluminium column speakers belies the
sophistication of the technology that makes
them sound so authoritative.
Flanked by a pair of long-throw bass drivers
with ultra-low distortion motor systems and
with KEF’s Uni-Q array the KHT5005.2
disperses a seamless sonic image evenly
throughout the listening area.
And what an image it is - richly textured and
spatially precise in every dimension.
Whether you’re watching a film or chilling
out to a few tracks, they sound as clean as
they look.
The sensational HTB2SE subwoofer pumps
out a genius distortion-free bass and with
the SmartBass
TM
‘connect and go’ technology
compliments the perfect beat and
sophistication of the satellites.
The 5000 Series is also available with
Wireless technology for the two rear
satellites, providing freedom to locate almost
anywhere without the worry of hiding
lengthy speaker cables.
Available in high gloss black and matt
silver finishes.
KHT3005SE KHT5005.2 / KHT5005.2W
SSppeecciiffiiccaattiioonnss
HHTTSS55000011..22//HHTTCC55000011..22
SSppeecciiffiiccaattiioonnss
HHTTBB22SSEE SSuubbwwooooffeerr
HHTTSS33000011SSEE SSaatteelllliittee
HHTTSS33000011SSEE CCeennttrree HHTTBB22SSEE SSuubbwwooooffeerr
Design Two-way bass reflex Three-way closed-box Powered Subwoofer
with passive radiator
Drive units 115mm (4.5in.) Uni-Q array with 115mm (4.5in.) Uni-Q array with 1 x 250mm (10in.) +
19mm (0.75in.) aluminium HF 19mm (0.75in.) aluminium HF 1 x 250mm (10in.) ABR
2 x 75mm (3in.) LF
Frequency response (±3dB) 70Hz - 55kHz 65Hz - 55kHz 30Hz - 250Hz
Crossover frequency 2.2kHz 500Hz, 2.2kHz N/A
Power handling 100W 100W N/A
Amplifier N/A N/A 250W built-in Class-D
Sensitivity (2.83V/1m) 88dB 90dB N/A
Maximum output (SPL) 108dB 110dB 110dB
Impedance 8Ω 8Ω N/A
Magnetic shielding Yes Yes Yes
Internal volume 1.8litres 2.4litres 15.0litres
Weight 2.0kg (4.5lbs) 2.6kg (5.8lbs) 11.3kg (24.9lbs)
Dimensions 245 x 125 x 150 mm 130 x 300 x 185 mm 390 x 440 x 195 mm (vertical)
(H x W x D) (9.6 x 4.9 x 5.9 in.) (5.1 x 11.8 x 7.3 in.) (15.4 x 17.3 x 7.7 in.)
227 x 440 x 385 mm (horizontal)
(8.9 x 17.3 x 15.2 in.)
Finish High gloss black, high gloss silver High gloss black, high gloss silver High gloss black, high gloss silver
Optional accessories Floorstand N/A N/A
Design Three-way closed box Satellite/Centre Powered Subwoofer with passive radiator
Drive units 75mm (3in.) Uni-Q array with 1 x 250mm (10in.) +
15mm (0.6in.) aluminium HF 1 x 250 mm (10in.) ABR
2 x 75mm (3in.) LF
Frequency response (±3dB) 95Hz - 30kHz 30Hz - 250Hz
Crossover frequency 300Hz, 3kHz N/A
Power handling 100W N/A
Amplifier N/A 250W built-in Class-D
Sensitivity (2.83V/1m) 87dB N/A
Maximum output (SPL) 106dB 110dB
Impedance 8Ω N/A
Magnetic shielding Yes Yes
Internal volume 1.4litres 15litres
Weight 2.0kg (4.4lbs) 11.3kg (24.9lbs)
Dimensions Satellite 419 x 88 x 127 mm 390 x 440 x 195 mm (vertical)
(H x W x D) (16.5 x 3.5 x 5.0 in.) (15.4 x 17.3 x 7.7 in.)
Centre 88 x 419 x 127 mm 227 x 440 x 385 mm (horizontal)
(3.5 x 16.5 x 5.0 in.) (8.9 x 17.3 x 15.2 in.)
Finish High gloss black, matt silver High gloss black, high gloss silver
Optional accessories Height adjustable desktop stand N/A
Floorstand
