Sound reproduction should be invisible - you
want surround sound, with the hardware as
unobtrusive as possible.
That’s why we came up with an alternative.
As its name implies, the fivetwo series
envelops you in the surround sound of a full
5.1 set-up using only two speakers and a
subwoofer (optional).
Whether you choose the compact model 7
(with seven drivers in each speaker) or the
formidable model 11 (with no less than
eleven), the effect is amazing. Voices sound
real and precisely located. Ambient effects
travel through a realistic three-dimensional
soundscape as the director intended.
On screen action comes alive for everyone
in the room, wherever they sit. The secret
lies in combining KEF’s acclaimed Uni-Q
“sit anywhere” driver concept with NXT flat
panel technology. Each speaker has a front-
firing array of Uni-Q drivers providing true
dedicated centre speakers as well as
spreading a highly detailed sound image to
your left and right.
Behind them, large vertical flat panels act as
high performance rear effect speakers.
And all the channels can be separately
adjusted from your receiver to achieve a
perfectly balanced sound.
Available in high gloss black or matt
silver finishes.
model 7 & model 11
If the problem of hiding lengthy cables has
restricted where you put your loudspeakers,
now you have the freedom to locate them
virtually anywhere you wish. KEF have
developed a remarkable innovation in audio
quality and convenience that at last makes
high-performing wireless speakers a reality.
A remarkable combination of signal
transmission, reception and processing
technologies combine to ensure superb
signal reliability and a CD-quality sound
transmission that is a match for even the
most demanding audio systems.
KEF Wireless System is an ideal add-on for
any existing rear surround sound speaker
set-up (regardless of the brand), and can be
also used for stereo speakers in a hi-fi
system where hiding the cables is an
inconvenience.
This remarkable technology is available as
either a stand-alone kit to support an existing
system or a complete 5.1 home theatre
system in the 5000 Series.
Wireless System is available in high
gloss black.
Wireless System / Wireless 5000 series
MMOODDEELL 77
SSppeecciiffiiccaattiioonnss
MMOODDEELL 1111
Design Closed-box surround sound Closed-box surround sound
Drive units 7 Speaker drivers, comprising: 11 Speaker drivers, comprising:
Dedicated Centre Channel Dedicated Centre Channel
1 x 75mm (3in.) Uni-Q array with 1 x 75mm (3in.) Uni-Q array with
1 x 15mm (0.6in.) aluminium HF 1 x 15mm (0.6in.) aluminium HF
1 x 75mm (3in.) LF
Front Left/Right Channel Front Left/Right Channel
1 x 75mm (3in.) Uni-Q array with 1 x 75mm (3in.) Uni-Q array with
1 x 15mm (0.6in.) aluminium HF 1 x 15mm (0.6in.) aluminium HF
2 x 75mm (3in.) LF 4 x 75mm (3in.) LF
Rear Left/Right Channel Rear Left/Right Channel
1x NXT flat panel 2x NXT flat panels
Frequency range (±3dB) 100Hz - 30kHz 90Hz - 30kHz
Crossover frequency 400Hz, 5kHz 600Hz, 5kHz
Power handling 100W 100W
Sensitivity (2.83V/1m) 87dB 87dB
Maximum output (SPL) 104dB 109dB
Impedance 8Ω 8Ω
Internal volume 1.4litres 15litres
Weight 3.9kg (8.6lbs) 8kg (17.6lbs)
Dimensions 400 x 104 x 230 mm 1020 x 210 x 230 mm
(H x W x D) (15.7 x 4.1 x 9.1 in.) (40.2 x 8.3 x 9.1 in.)
Finish High gloss black, matt silver High gloss black, matt silver
Connectors Supplied with connection for any 5.1 Supplied with connection for any 5.1
home theatre receiver/amplifier home theatre receiver/amplifier
Optional accessories Floorstand Wall bracket
Wall bracket
KKHHTT55000055..22WW
SSppeecciiffiiccaattiioonnss
WWiirreelleessss SSyysstteemm
* Environmental factors such as building materials and construction may adversely affect wireless signal range.
Transmission protocol AAFHSS AAFHSS
Frequency band 2.4 -2.4835GHz (ISM band) 2.4 -2.4835GHz (ISM band)
Data rate Up to 1.1Mbps Up to 1.1Mbps
Range 25m Typical maximum* (27.3yds) 25m Typical maximum* (27.3yds)
Amplifier 2x 50W (digital amplifiers) 2x 50W (digital amplifiers)
Sensitivity 80dB 80dB
Frequency response (±3dB) 20Hz - 20kHz 20Hz - 20kHz
Peak audio output 50W rms 50W rms
Crossover frequency 800Hz and 5kHz N/A
Transmitter module 147 x 79 x 79 mm 147 x 79 x 79 mm
Dimensions (H x W x D) (5.8 x 3.1 x 3.1 in.) (5.8 x 3.1 x 3.1 in.)
Receiver module Additional 50mm (height on floorstand) 147 x 79 x 79 mm (H x W x D)
Dimensions Additional 122mm (height on deskstand) (5.8 x 3.1 x 3.1 in.)
(Additional 4.8in.)
(Additional 2in.)
Finish High gloss black, matt silver High gloss black
