Figure 5
Wire dressing — Model 7702
Connection log
Make a copy of T
able 2 and af
fix it to the cov
er of the Model 7702. Use this to record connection information and channel
descriptions as needed.
TE122
TE121
Cable tie
(2 places)
Supplementary
Insulation
T
14
16
